因为Task要写入到本地数据库，所以mId作为唯一键。有了数据来源再定义本地数据仓库，数据仓库向activity提供数据，并且实现上面的三级缓存原理。数据仓库中处理三种来源的数据，并将最后的结果返回。数据仓库TasksRepository

public class

TasksRepository implements TasksDataSource {

private static TasksRepository INSTANCE = null;

private final TasksDataSource mTasksRemoteDataSource;//服务器数据来源

private final TasksDataSource mTasksLocalDataSource;//本地数据库数据源

Map<String, Task> mCachedTasks;//内存缓存

boolean mCacheIsDirty = false;//标记缓存数据是否脏

// Prevent direct instantiation.
private TasksRepository(@NonNull TasksDataSource tasksRemoteDataSource,
@NonNull TasksDataSource tasksLocalDataSource) {
mTasksRemoteDataSource = checkNotNull(tasksRemoteDataSource);
mTasksLocalDataSource = checkNotNull(tasksLocalDataSource);
}

public static TasksRepository getInstance(TasksDataSource tasksRemoteDataSource,
TasksDataSource tasksLocalDataSource) {
if (INSTANCE == null) {
INSTANCE = new TasksRepository(tasksRemoteDataSource, tasksLocalDataSource);
}
return INSTANCE;
}

public static void destroyInstance() {
INSTANCE = null;
}
//获取任务
@Override
public void getTasks(@NonNull final LoadTasksCallback callback) {
checkNotNull(callback);

// Respond immediately with cache if available and not dirty
if (mCachedTasks != null && !mCacheIsDirty) {
callback.onTasksLoaded(new ArrayList<>(mCachedTasks.values()));
return;
}

if (mCacheIsDirty) {
// If the cache is dirty we need to fetch new data from the network.
getTasksFromRemoteDataSource(callback);
} else {
// Query the local storage if available. If not, query the network.
mTasksLocalDataSource.getTasks(new LoadTasksCallback() {
@Override
public void onTasksLoaded(List tasks) {
refreshCache(tasks);
callback.onTasksLoaded(new ArrayList<>(mCachedTasks.values()));
}

@Override
public void onDataNotAvailable() {
getTasksFromRemoteDataSource(callback);
}
});
}
}
//保存任务
@Override
public void saveTask(@NonNull Task task) {
checkNotNull(task);
mTasksRemoteDataSource.saveTask(task);
mTasksLocalDataSource.saveTask(task);

// Do in memory cache update to keep the app UI up to date
if (mCachedTasks == null) {
mCachedTasks = new LinkedHashMap<>();
}
mCachedTasks.put(task.getId(), task);
}
//通过taskid获取任务
@Override
public void getTask(@NonNull final String taskId, @NonNull final GetTaskCallback callback) {
checkNotNull(taskId);
checkNotNull(callback);

Task cachedTask = getTaskWithId(taskId);

// Respond immediately with cache if available
if (cachedTask != null) {
callback.onTaskLoaded(cachedTask);
return;
}

// Load from server/persisted if needed.

// Is the task in the local data source? If not, query the network.
mTasksLocalDataSource.getTask(taskId, new GetTaskCallback() {
@Override
public void onTaskLoaded(Task task) {
// Do in memory cache update to keep the app UI up to date
if (mCachedTasks == null) {
mCachedTasks = new LinkedHashMap<>();
}
mCachedTasks.put(task.getId(), task);
callback.onTaskLoaded(task);
}

@Override
public void onDataNotAvailable() {
mTasksRemoteDataSource.getTask(taskId, new GetTaskCallback() {
@Override
public void onTaskLoaded(Task task) {
// Do in memory cache update to keep the app UI up to date
if (mCachedTasks == null) {
mCachedTasks = new LinkedHashMap<>();
}
mCachedTasks.put(task.getId(), task);
callback.onTaskLoaded(task);
}

@Override
public void onDataNotAvailable() {
callback.onDataNotAvailable();
}
});
}
});
}
//刷新任务
@Override
public void refreshTasks() {
mCacheIsDirty = true;
}
//删除全部任务
@Override
public void deleteAllTasks() {
mTasksRemoteDataSource.deleteAllTasks();
mTasksLocalDataSource.deleteAllTasks();

if (mCachedTasks == null) {
mCachedTasks = new LinkedHashMap<>();
}
mCachedTasks.clear();
}
//删除任务
@Override
public void deleteTask(@NonNull String taskId) {
mTasksRemoteDataSource.deleteTask(checkNotNull(taskId));
mTasksLocalDataSource.deleteTask(checkNotNull(taskId));

mCachedTasks.remove(taskId);
}
//从服务器获取数据
private void getTasksFromRemoteDataSource(@NonNull final LoadTasksCallback callback) {
mTasksRemoteDataSource.getTasks(new LoadTasksCallback() {
@Override
public void onTasksLoaded(List tasks) {
refreshCache(tasks);
refreshLocalDataSource(tasks);
callback.onTasksLoaded(new ArrayList<>(mCachedTasks.values()));
}

@Override
public void onDataNotAvailable() {
callback.onDataNotAvailable();
}
});
}
//刷新缓存数据
private void refreshCache(List tasks) {
if (mCachedTasks == null) {
mCachedTasks = new LinkedHashMap<>();
}
mCachedTasks.clear();
for (Task task : tasks) {
mCachedTasks.put(task.getId(), task);
}
mCacheIsDirty = false;
}
//刷新本地数据库
private void refreshLocalDataSource(List tasks) {
mTasksLocalDataSource.deleteAllTasks();
for (Task task : tasks) {
mTasksLocalDataSource.saveTask(task);
}
}

}

本地数据来源类TasksLocalDataSource

public class TasksLocalDataSource implements TasksDataSource {

private static volatile TasksLocalDataSource INSTANCE;

private TasksDao mTasksDao;

private AppExecutors mAppExecutors;

// Prevent direct instantiation.
private TasksLocalDataSource(@NonNull AppExecutors appExecutors,
@NonNull TasksDao tasksDao) {
mAppExecutors = appExecutors;
mTasksDao = tasksDao;
}

public static TasksLocalDataSource getInstance(@NonNull AppExecutors appExecutors,
@NonNull TasksDao tasksDao) {
if (INSTANCE == null) {
synchronized (TasksLocalDataSource.class) {
if (INSTANCE == null) {
INSTANCE = new TasksLocalDataSource(appExecutors, tasksDao);
}
}
}
return INSTANCE;
}

/**

Note: {@link LoadTasksCallback#onDataNotAvailable()} is fired if the database doesn’t exist
or the table is empty.
*/
@Override
public void getTasks(@NonNull final LoadTasksCallback callback) {
Runnable runnable = new Runnable() {
@Override
public void run() {
final List tasks = mTasksDao.getTasks();
mAppExecutors.mainThread().execute(new Runnable() {
@Override
public void run() {
if (tasks.isEmpty()) {
// This will be called if the table is new or just empty.
callback.onDataNotAvailable();
} else {
callback.onTasksLoaded(tasks);
}
}
});
}
};

mAppExecutors.diskIO().execute(runnable);
}

/**

Note: {@link GetTaskCallback#onDataNotAvailable()} is fired if the {@link Task} isn’t
found.
*/
@Override
public void getTask(@NonNull final String taskId, @NonNull final GetTaskCallback callback) {
Runnable runnable = new Runnable() {
@Override
public void run() {
final Task task = mTasksDao.getTaskById(taskId);

mAppExecutors.mainThread().execute(new Runnable() {
@Override
public void run() {
if (task != null) {
callback.onTaskLoaded(task);
} else {
callback.onDataNotAvailable();
}
}
});
}
};

mAppExecutors.diskIO().execute(runnable);
}

@Override
public void saveTask(@NonNull final Task task) {
checkNotNull(task);
Runnable saveRunnable = new Runnable() {
@Override
public void run() {
mTasksDao.insertTask(task);
}
};
mAppExecutors.diskIO().execute(saveRunnable);
}

@Override
public void completeTask(@NonNull final Task task) {
Runnable completeRunnable = new Runnable() {
@Override
public void run() {
mTasksDao.updateCompleted(task.getId(), true);
}
