动画效果Glow和发射器Emitter

import QtQuick 2.12
import QtQuick.Window 2.12
import QtCharts 2.3
import QtQuick.Controls 2.12
import QtQml.Models 2.12
import QtQuick.XmlListModel 2.12
import QtGraphicalEffects 1.0
import QtQuick.Particles 2.12

Window {
    visible: true
    width: 640
    height: 480
    title: qsTr("Hello World")
    color: "gray"
    ParticleSystem{
        id:particlesystem

    }
    Emitter{  //发射器
        id:emitter
        anchors.fill: parent
        width: 300
        height: 400
        system: particlesystem //粒子 系统
        emitRate: 10 //发射粒子的速度
        lifeSpan: 6000 //粒子的存在时间
        lifeSpanVariation: 400 //数量
        size:15
        velocity: PointDirection{
            x:-45 //生成的方向，设置之后会一致在左边生成  -45左   45 是右
        }

    }
    ImageParticle{
        id:img
        source: "file:///C++/C++.png"
        system: particlesystem
        color: Qt.rgba(152/255,217/255,234/255,1.0)
        colorVariation: 0.3 //根据color随机修改颜色。
    }
    Attractor{ //吸引
        anchors.fill:parent
        system: particlesystem
        enabled: true
        pointX: mouse.mouseX
        pointY: mouse.mouseY
        strength: 1000000  //负数是弹开  整数是吸引
        affectedParameter: Attractor.Acceleration
        proportionalToDistance: Attractor.InverseQuadratic  //设置方式
    }
    MouseArea{
        id:mouse
        hoverEnabled: true
        anchors.fill: parent
    }
    BusyIndicator{
        width: 100
        height: 100
        anchors.bottom: parent.bottom
        anchors.horizontalCenter: parent.horizontalCenter
        anchors.bottomMargin: 20
    }



    Text {
           id: txt
           text: qsTr("Waitting")
           font.pixelSize: 70
           anchors.centerIn: parent
       }
       Glow{ //发光效果
           anchors.fill: txt
           radius: 8
           samples: 17
           color: "white"
           source: txt
           id:glow
           SequentialAnimation{ //队列的动画效果
               running: true
               loops:Animation.Infinite //动画效果无限出现。
               NumberAnimation{
                   target: glow
                   property: "spread"
                   to:0
                   duration: 1000
               }
               NumberAnimation{
                   target: glow
                   property: "spread"
                   to:0.5
                   duration: 1000
               }
           }
       }

}

FLoderListModel

import QtQuick 2.12
import QtQuick.Window 2.12
import QtCharts 2.3
import QtQuick.Controls 2.12
import QtQml.Models 2.12
import QtQuick.XmlListModel 2.12
import QtGraphicalEffects 1.0
import QtQuick.Particles 2.12
import Qt.labs.folderlistmodel 2.12

Window {
    visible: true
    width: 640
    height: 480
    title: qsTr("Hello World")
    color: "gray"

    ListView {
        width: 200; height: 400
        FolderListModel {
            id: folderModel
            nameFilters: ["*.qml"]  //查看当前路径下的所有文件
            showDirs: false //不显示文件夹
            folder: "./"
            showDirsFirst: true //先排序文件夹
        }

        model: folderModel
        delegate:     Text { text: fileName }
    }
}

Settings

import QtQuick 2.12
import QtQuick.Window 2.12
import QtCharts 2.3
import QtQuick.Controls 2.12
import QtQml.Models 2.12
import QtQuick.XmlListModel 2.12
import QtGraphicalEffects 1.0
import QtQuick.Particles 2.12
import Qt.labs.folderlistmodel 2.12
import Qt.labs.settings 1.0

Window {
    visible: true
    width: 640
    height: 480
    title: qsTr("Hello World")
    Text {
        id: txt
        text: settings.val
        font.pixelSize: 40

    }

    Settings{
        id:settings
        fileName: "./setting.ini" //设置文件，不设置在注册表中Windows系统。
        property int val: 0
        property double d:1.24 //只能使用基本类型。不能保存qml对象
//        category: "other" //设置分组
        property var myvar: [1,2,3,"fa"]
        property string  qstr: "mystr"



    }
    Button{
        id:btn
        width: 100
        height: 50
        x:100
        onClicked: {
             settings.val+=1;
            console.log( settings.value("mystr",-1) ) //存在输出，不存在输出-1
           settings.setValue(val,100) //设置value

        }
    }
}
