# -*- coding: utf-8 -*-
import sys
import os
import cv2
import numpy as np
from PyQt5.QtWidgets import (QApplication, QMainWindow, QPushButton, QWidget,
QVBoxLayout, QHBoxLayout, QMessageBox, QLabel,
QFileDialog, QToolBar, QComboBox, QStatusBar)
from PyQt5.QtCore import QRect, Qt
from CamOperation_class import CameraOperation
sys.path.append("D:\\海康\\MVS\\Development\\Samples\\Python\\BasicDemo")
from MvCameraControl_class import *
from MvErrorDefine_const import *
from CameraParams_header import *
from PyUICBasicDemo import Ui_MainWindow
import ctypes
from datetime import datetime
import logging
# 配置日志系统
logging.basicConfig(
level=logging.INFO,
format='%(asctime)s - %(name)s - %(levelname)s - %(message)s',
handlers=[
logging.FileHandler("cloth_inspection.log"),
logging.StreamHandler()
]
)
logging.info("布料印花检测系统启动")
# 全局变量
current_sample_path = "" # 当前使用的样本路径
detection_history = [] # 检测历史记录
# 布料印花检测函数
def check_print_quality(sample_image_path, test_image_path, threshold=0.05):
"""
检测布料印花是否合格,并在合格样本上标出错误位置
:param sample_image_path: 合格样本图像路径
:param test_image_path: 待检测图像路径
:param threshold: 差异阈值,超过该值则认为印花不合格
:return: 是否合格,差异值,带有错误标记的合格样本图像
"""
# 读取图像
sample_image = cv2.imread(sample_image_path, cv2.IMREAD_GRAYSCALE)
test_image = cv2.imread(test_image_path, cv2.IMREAD_GRAYSCALE)
if sample_image is None or test_image is None:
logging.error("无法加载图像,请检查路径是否正确!")
return None, None, None
# 确保两个图像大小一致
test_image = cv2.resize(test_image, (sample_image.shape[1], sample_image.shape[0]))
# 计算两个图像之间的差异
diff = cv2.absdiff(sample_image, test_image)
# 将差异图像二值化
ret, diff_binary = cv2.threshold(diff, 50, 255, cv2.THRESH_BINARY)
# 计算差异的占比
diff_ratio = np.sum(diff_binary) / (diff_binary.shape[0] * diff_binary.shape[1] * 255) # 修正计算方式
# 判断是否合格
is_qualified = diff_ratio < threshold
# 在合格样本上标出错误位置
if is_qualified:
marked_image = cv2.cvtColor(sample_image, cv2.COLOR_GRAY2BGR)
else:
marked_image = cv2.cvtColor(sample_image, cv2.COLOR_GRAY2BGR)
contours, _ = cv2.findContours(diff_binary, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE)
cv2.drawContours(marked_image, contours, -1, (0, 0, 255), 2)
return is_qualified, diff_ratio, marked_image
# 布料印花检测功能
def check_print():
global isGrabbing, obj_cam_operation, current_sample_path, detection_history
if not isGrabbing:
QMessageBox.warning(mainWindow, "错误", "请先开始取流并捕获图像!", QMessageBox.Ok)
return
# 检查样本路径是否有效
if not current_sample_path or not os.path.exists(current_sample_path):
QMessageBox.warning(mainWindow, "错误", "请先设置有效的标准样本图像!", QMessageBox.Ok)
return
# 保存当前帧作为测试图像
test_path = "temp_test_image.bmp"
ret = obj_cam_operation.save_bmp()
if ret != MV_OK:
QMessageBox.warning(mainWindow, "错误", "保存测试图像失败!", QMessageBox.Ok)
return
# 执行印花检测
is_qualified, diff_ratio, marked_image = check_print_quality(current_sample_path, test_path)
if marked_image is not None:
# 显示结果
result_text = f"印花是否合格: {'合格' if is_qualified else '不合格'}\n差异占比: {diff_ratio:.4f}"
QMessageBox.information(mainWindow, "检测结果", result_text, QMessageBox.Ok)
# 显示标记图像
cv2.imshow("缺陷标记结果", marked_image)
cv2.waitKey(0)
cv2.destroyAllWindows()
# 记录检测结果
detection_result = {
'timestamp': datetime.now(),
'qualified': is_qualified,
'diff_ratio': diff_ratio,
'sample_path': current_sample_path,
'test_path': test_path
}
detection_history.append(detection_result)
update_history_display()
# 保存标准样本函数
def save_sample_image():
global isGrabbing, obj_cam_operation, current_sample_path
if not isGrabbing:
QMessageBox.warning(mainWindow, "错误", "请先开始取流并捕获图像!", QMessageBox.Ok)
return
# 弹出文件保存对话框
file_path, _ = QFileDialog.getSaveFileName(
mainWindow,
"保存标准样本图像",
"",
"BMP Files (*.bmp);;PNG Files (*.png);;JPEG Files (*.jpg)"
)
if not file_path:
return # 用户取消保存
# 获取文件扩展名
file_extension = os.path.splitext(file_path)[1].lower()
# 根据扩展名设置保存格式
if file_extension == ".bmp":
save_format = "bmp"
elif file_extension == ".png":
save_format = "png"
elif file_extension == ".jpg" or file_extension == ".jpeg":
save_format = "jpeg"
else:
QMessageBox.warning(mainWindow, "错误", "不支持的文件格式!", QMessageBox.Ok)
return
# 保存当前帧作为标准样本
ret = obj_cam_operation.save_image(file_path, save_format)
if ret != MV_OK:
strError = "保存样本图像失败: " + ToHexStr(ret)
QMessageBox.warning(mainWindow, "错误", strError, QMessageBox.Ok)
else:
QMessageBox.information(mainWindow, "成功", f"标准样本已保存至:\n{file_path}", QMessageBox.Ok)
# 更新当前样本路径
current_sample_path = file_path
update_sample_display()
# 预览当前样本
def preview_sample():
global current_sample_path
if not current_sample_path or not os.path.exists(current_sample_path):
QMessageBox.warning(mainWindow, "错误", "请先设置有效的标准样本图像!", QMessageBox.Ok)
return
try:
sample_img = cv2.imread(current_sample_path)
if sample_img is None:
raise Exception("无法加载图像")
cv2.imshow("标准样本预览", sample_img)
except Exception as e:
QMessageBox.warning(mainWindow, "错误", f"预览样本失败: {str(e)}", QMessageBox.Ok)
# 更新样本路径显示
def update_sample_display():
global current_sample_path
if current_sample_path:
ui.lblSamplePath.setText(f"当前样本: {os.path.basename(current_sample_path)}")
ui.lblSamplePath.setToolTip(current_sample_path)
else:
ui.lblSamplePath.setText("当前样本: 未设置样本")
# 更新历史记录显示
def update_history_display():
global detection_history
ui.cbHistory.clear()
for i, result in enumerate(detection_history[-10:]): # 显示最近10条记录
timestamp = result['timestamp'].strftime("%H:%M:%S")
status = "合格" if result['qualified'] else "不合格"
ratio = f"{result['diff_ratio']:.4f}"
ui.cbHistory.addItem(f"[{timestamp}] {status} - 差异: {ratio}")
# 获取选取设备信息的索引,通过[]之间的字符去解析
def TxtWrapBy(start_str, end, all):
start = all.find(start_str)
if start >= 0:
start += len(start_str)
end = all.find(end, start)
if end >= 0:
return all[start:end].strip()
# 将返回的错误码转换为十六进制显示
def ToHexStr(num):
"""将错误码转换为十六进制字符串"""
# 处理非整数输入
if not isinstance(num, int):
try:
# 尝试转换为整数
num = int(num)
except:
# 无法转换时返回类型信息
return f"<非整数:{type(num)}>"
chaDic = {10: 'a', 11: 'b', 12: 'c', 13: 'd', 14: 'e', 15: 'f'}
hexStr = ""
# 处理负数
if num < 0:
num = num + 2 ** 32
# 转换为十六进制
while num >= 16:
digit = num % 16
hexStr = chaDic.get(digit, str(digit)) + hexStr
num //= 16
hexStr = chaDic.get(num, str(num)) + hexStr
return "0x" + hexStr
# ch:初始化SDK | en: initialize SDK
MvCamera.MV_CC_Initialize()
global deviceList
deviceList = MV_CC_DEVICE_INFO_LIST()
global cam
cam = MvCamera()
global nSelCamIndex
nSelCamIndex = 0
global obj_cam_operation
obj_cam_operation = 0
global isOpen
isOpen = False
global isGrabbing
isGrabbing = False
global isCalibMode # 是否是标定模式(获取原始图像)
isCalibMode = True
# 绑定下拉列表至设备信息索引
def xFunc(event):
global nSelCamIndex
nSelCamIndex = TxtWrapBy("[", "]", ui.ComboDevices.get())
# Decoding Characters
def decoding_char(c_ubyte_value):
c_char_p_value = ctypes.cast(c_ubyte_value, ctypes.c_char_p)
try:
decode_str = c_char_p_value.value.decode('gbk') # Chinese characters
except UnicodeDecodeError:
decode_str = str(c_char_p_value.value)
return decode_str
# ch:枚举相机 | en:enum devices
def enum_devices():
global deviceList
global obj_cam_operation
deviceList = MV_CC_DEVICE_INFO_LIST()
n_layer_type = (MV_GIGE_DEVICE | MV_USB_DEVICE | MV_GENTL_CAMERALINK_DEVICE
| MV_GENTL_CXP_DEVICE | MV_GENTL_XOF_DEVICE)
ret = MvCamera.MV_CC_EnumDevices(n_layer_type, deviceList)
if ret != 0:
strError = "Enum devices fail! ret = :" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
return ret
if deviceList.nDeviceNum == 0:
QMessageBox.warning(mainWindow, "Info", "Find no device", QMessageBox.Ok)
return ret
print("Find %d devices!" % deviceList.nDeviceNum)
devList = []
for i in range(0, deviceList.nDeviceNum):
mvcc_dev_info = cast(deviceList.pDeviceInfo[i], POINTER(MV_CC_DEVICE_INFO)).contents
if mvcc_dev_info.nTLayerType == MV_GIGE_DEVICE or mvcc_dev_info.nTLayerType == MV_GENTL_GIGE_DEVICE:
print("\ngige device: [%d]" % i)
user_defined_name = decoding_char(mvcc_dev_info.SpecialInfo.stGigEInfo.chUserDefinedName)
model_name = decoding_char(mvcc_dev_info.SpecialInfo.stGigEInfo.chModelName)
print("device user define name: " + user_defined_name)
print("device model name: " + model_name)
nip1 = ((mvcc_dev_info.SpecialInfo.stGigEInfo.nCurrentIp & 0xff000000) >> 24)
nip2 = ((mvcc_dev_info.SpecialInfo.stGigEInfo.nCurrentIp & 0x00ff0000) >> 16)
nip3 = ((mvcc_dev_info.SpecialInfo.stGigEInfo.nCurrentIp & 0x0000ff00) >> 8)
nip4 = (mvcc_dev_info.SpecialInfo.stGigEInfo.nCurrentIp & 0x000000ff)
print("current ip: %d.%d.%d.%d " % (nip1, nip2, nip3, nip4))
devList.append(
"[" + str(i) + "]GigE: " + user_defined_name + " " + model_name + "(" + str(nip1) + "." + str(
nip2) + "." + str(nip3) + "." + str(nip4) + ")")
elif mvcc_dev_info.nTLayerType == MV_USB_DEVICE:
print("\nu3v device: [%d]" % i)
user_defined_name = decoding_char(mvcc_dev_info.SpecialInfo.stUsb3VInfo.chUserDefinedName)
model_name = decoding_char(mvcc_dev_info.SpecialInfo.stUsb3VInfo.chModelName)
print("device user define name: " + user_defined_name)
print("device model name: " + model_name)
strSerialNumber = ""
for per in mvcc_dev_info.S极Info.stUsb3VInfo.chSerialNumber:
if per == 0:
break
strSerialNumber = strSerialNumber + chr(per)
print("user serial number: " + strSerialNumber)
devList.append("[" + str(i) + "]USB: " + user_defined_name + " " + model_name
+ "(" + str(strSerialNumber) + ")")
elif mvcc_dev_info.nTLayerType == MV_GENTL_CAMERALINK_DEVICE:
print("\nCML device: [极d]" % i)
user_defined_name = decoding_char(mvcc_dev_info.SpecialInfo.stCMLInfo.chUserDefinedName)
model_name = decoding_char(mvcc_dev_info.SpecialInfo.stCMLInfo.chModelName)
print("device user define name: " + user_defined_name)
print("device model name: " + model_name)
strSerialNumber = ""
for per in mvcc_dev_info.SpecialInfo.stCMLInfo.chSerialNumber:
if per == 0:
break
strSerialNumber = strSerialNumber + chr(per)
print("user serial number: " + strSerialNumber)
devList.append("[" + str(i) + "]CML: " + user_defined_name + " " + model_name
+ "(" + str(strSerialNumber) + ")")
elif mvcc_dev_info.nTLayerType == MV_GENTL_CXP_DEVICE:
print("\nCXP device: [%d]" % i)
user_defined_name = decoding_char(mvcc_dev_info.SpecialInfo.stCXPInfo.chUserDefinedName)
model_name = decoding_char(mvcc_dev_info.SpecialInfo.stCXPInfo.chModelName)
print("device user define name: " + user_defined_name)
print("device model name: " + model_name)
strSerialNumber = ""
for per in mvcc_dev_info.SpecialInfo.stCXPInfo.chSerialNumber:
if per == 0:
break
strSerialNumber = strSerialNumber + chr(per)
print("user serial number: " + strSerialNumber)
devList.append("[" + str(i) + "]CXP: " + user_defined_name + " " + model_name
+ "(" + str(strSerialNumber) + ")")
elif mvcc_dev_info.nTLayerType == MV_GENTL_XOF_DEVICE:
print("\nXoF device: [%d]" % i)
user_defined_name = decoding_char(mvcc_dev_info.SpecialInfo.stXoFInfo.chUserDefinedName)
model_name = decoding_char(mvcc_dev_info.SpecialInfo.stXoFInfo.chModelName)
print("device user define name: " + user_defined_name)
print("device model name: " + model_name)
strSerialNumber = ""
for per in mvcc_dev_info.SpecialInfo.stXoFInfo.chSerialNumber:
if per == 0:
break
strSerialNumber = strSerialNumber + chr(per)
print("user serial number: " + strSerialNumber)
devList.append("[" + str(i) + "]XoF: " + user_defined_name + " " + model_name
+ "(" + str(strSerialNumber) + ")")
ui.ComboDevices.clear()
ui.ComboDevices.addItems(devList)
ui.ComboDevices.setCurrentIndex(0)
# ch:打开相机 | en:open device
def open_device():
global deviceList
global nSelCamIndex
global obj_cam_operation
global isOpen
if isOpen:
QMessageBox.warning(mainWindow, "Error", 'Camera is Running!', QMessageBox.Ok)
return MV_E_CALLORDER
nSelCamIndex = ui.ComboDevices.currentIndex()
if nSelCamIndex < 0:
QMessageBox.warning(mainWindow, "Error", 'Please select a camera!', QMessageBox.Ok)
return MV_E_CALLORDER
obj_cam_operation = CameraOperation(cam, deviceList, nSelCamIndex)
ret = obj_cam_operation.open_device()
if 0 != ret:
strError = "Open device failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
isOpen = False
else:
set_continue_mode()
get_param()
isOpen = True
enable_controls()
# ch:开始取流 | en:Start grab image
def start_grabbing():
global obj_cam_operation
global isGrabbing
ret = obj_cam_operation.start_grabbing(ui.widgetDisplay.winId())
if ret != 0:
strError = "Start grabbing failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
else:
isGrabbing = True
enable_controls()
# ch:停止取流 | en:Stop grab image
def stop_grabbing():
global obj_cam_operation
global isGrabbing
ret = obj_cam_operation.Stop_grabbing()
if ret != 0:
strError = "Stop grabbing failed ret:" + ToHexStr
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
else:
isGrabbing = False
enable_controls()
# ch:关闭设备 | Close device
def close_device():
global isOpen
global isGrabbing
global obj_cam_operation
if isOpen:
obj_cam_operation.close_devicelose_device()
isOpen = False
isGrabbing = False
enable_controls()
# ch:设置触发模式 | en:set trigger mode
def set_continue_mode():
ret = obj_cam_operation.set_trigger_mode(False)
if ret != 0:
strError = "Set continue mode failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
else:
ui.radioContinueMode.setChecked(True)
ui.radioTriggerMode.setChecked(False)
ui.bnSoftwareTrigger.setEnabled(False)
# ch:设置软触发模式 | en:set software trigger mode
def set_software_trigger_mode():
ret = obj_cam_operation.set_trigger_mode(True)
if ret != 0:
strError = "Set trigger mode failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
else:
ui.radioContinueMode.setChecked(False)
ui.radioTriggerMode.setChecked(True)
ui.bnSoftwareTrigger.setEnabled(isGrabbing)
# ch:设置触发命令 | en:set trigger software
def trigger_once():
ret = obj_cam_operation.trigger_once()
if ret != 0:
strError = "TriggerSoftware failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
# ch:存图 | en:save image
def save_bmp():
ret = obj_cam_operation.save_bmp()
if ret != MV_OK:
strError = "Save BMP failed ret:" + ToHexStr(ret)
QMessageBox.warning(mainWindow, "Error", strError, QMessageBox.Ok)
else:
print("Save image success")
def is_float(str):
try:
float(str)
return True
except ValueError:
return False
# ch: 获取参数 | en:get param
def get_param():
try:
# 调用方法获取参数
ret = obj_cam_operation.get_param()
# 记录调用结果(调试用)
logging.debug(f"get_param() 返回: {ret} (类型: {type(ret)})")
# 处理错误码
if ret != MV_OK:
strError = "获取参数失败,错误码: " + ToHexStr(ret)
QMessageBox.warning(mainWindow, "错误", strError, QMessageBox.Ok)
else:
# 成功获取参数后更新UI
ui.edtExposureTime.setText("{0:.2f}".format(obj_cam_operation.exposure_time))
ui.edtGain.setText("{0:.2f}".format(obj_cam_operation.gain))
ui.edtFrameRate.setText("{0:.2f}".format(obj_cam_operation.frame_rate))
# 记录成功信息
logging.info("成功获取相机参数")
except Exception as e:
# 处理所有异常
error_msg = f"获取参数时发生错误: {str(e)}"
logging.error(error_msg)
QMessageBox.critical(mainWindow, "严重错误", error_msg, QMessageBox.Ok)
# ch: 设置参数 | en:set param
def set_param():
frame_rate = ui.edtFrameRate.text()
exposure = ui.edtExposureTime.text()
gain = ui.edtGain.text()
if not (is_float(frame_rate) and is_float(exposure) and is_float(gain)):
strError = "设置参数失败: 参数必须是有效的浮点数"
QMessageBox.warning(mainWindow, "错误", strError, QMessageBox.Ok)
return MV_E_PARAMETER
try:
# 使用正确的参数顺序和关键字
ret = obj_cam_operation.set_param(
frame_rate=float(frame_rate),
exposure_time=float(exposure),
gain=float(gain)
)
if ret != MV_OK:
strError = "设置参数失败,错误码: " + ToHexStr(ret)
QMessageBox.warning(mainWindow, "错误", strError, QMessageBox.Ok)
else:
logging.info("参数设置成功")
return MV_OK
except Exception as e:
error_msg = f"设置参数时发生错误: {str(e)}"
logging.error(error_msg)
QMessageBox.critical(mainWindow, "严重错误", error_msg, QMessageBox.Ok)
return MV_E_STATE
# ch: 设置控件状态 | en:set enable status
def enable_controls():
global isGrabbing
global isOpen
# 先设置group的状态,再单独设置各控件状态
ui.groupGrab.setEnabled(isOpen)
ui.groupParam.setEnabled(isOpen)
ui.bnOpen.setEnabled(not isOpen)
ui.bnClose.setEnabled(isOpen)
ui.bnStart.setEnabled(isOpen and (not isGrabbing))
ui.bnStop.setEnabled(isOpen and isGrabbing)
ui.bnSoftwareTrigger.setEnabled(isGrabbing and ui.radioTriggerMode.isChecked())
ui.bnSaveImage.setEnabled(isOpen and isGrabbing)
# 添加检测按钮控制
ui.bnCheckPrint.setEnabled(isOpen and isGrabbing)
ui.bnSaveSample.setEnabled(isOpen and isGrabbing)
ui.bnPreviewSample.setEnabled(bool(current_sample_path))
if __name__ == "__main__":
# ch:初始化SDK | en: initialize SDK
MvCamera.MV_CC_Initialize()
deviceList = MV_CC_DEVICE_INFO_LIST()
cam = MvCamera()
nSelCamIndex = 0
obj_cam_operation = 0
isOpen = False
isGrabbing = False
isCalibMode = True # 是否是标定模式(获取原始图像)
# 初始化UI
app = QApplication(sys.argv)
mainWindow = QMainWindow()
ui = Ui_MainWindow()
ui.setupUi(mainWindow)
# 扩大主窗口尺寸
mainWindow.resize(1200, 800) # 宽度1200,高度800
# 创建工具栏
toolbar = mainWindow.addToolBar("检测工具")
# 添加检测按钮
ui.bnCheckPrint = QPushButton("检测印花质量")
toolbar.addWidget(ui.bnCheckPrint)
# 添加保存样本按钮
ui.bnSaveSample = QPushButton("保存标准样本")
toolbar.addWidget(ui.bnSaveSample)
# 添加预览样本按钮
ui.bnPreviewSample = QPushButton("预览样本")
toolbar.addWidget(ui.bnPreviewSample)
# 添加历史记录下拉框
ui.cbHistory = QComboBox()
ui.cbHistory.setMinimumWidth(300)
toolbar.addWidget(QLabel("历史记录:"))
toolbar.addWidget(ui.cbHistory)
# 添加当前样本显示标签
ui.lblSamplePath = QLabel("当前样本: 未设置样本")
status_bar = mainWindow.statusBar()
status_bar.addPermanentWidget(ui.lblSamplePath)
# 绑定按钮事件
ui.bnCheckPrint.clicked.connect(check_print)
ui.bnSaveSample.clicked.connect(save_sample_image)
ui.bnPreviewSample.clicked.connect(preview_sample)
# 绑定其他按钮事件
ui.bnEnum.clicked.connect(enum_devices)
ui.bnOpen.clicked.connect(open_device)
ui.bnClose.clicked.connect(close_device)
ui.bnStart.clicked.connect(start_grabbing)
ui.bnStop.clicked.connect(stop_grabbing)
ui.bnSoftwareTrigger.clicked.connect(trigger_once)
ui.radioTriggerMode.clicked.connect(set_software_trigger_mode)
ui.radioContinueMode.clicked.connect(set_continue_mode)
ui.bnGetParam.clicked.connect(get_param)
ui.bnSetParam.clicked.connect(set_param)
ui.bnSaveImage.clicked.connect(save_bmp)
# 显示主窗口
mainWindow.show()
# 执行应用
app.exec_()
# 关闭设备
close_device()
# ch:反初始化SDK | en: finalize SDK
MvCamera.MV_CC_Finalize()
sys.exit()
这是one.py的程序按照你 刚刚的解答展示出完整代码
最新发布
