使用mybatis核心配置文件和映射文件做的完整项目_记录

记录下使用mybatis查询数据库的实例，此记录用于自己日后回归用。同时，用与于mybatis与spring 结合时，怎么结合配置文件的。

备注：

1、mybatis 有个核心配置文件，用于设置日志、配置数据库信息、简称、注册mapper映射文件等。

2、有个Mapper映射文件，与Dao接口进行对应。





1、实体类

public class User {
    private  int id;
    private String username;
    private  int password;
    private  int age;
    private  String sex;

    public int getId() {
        return id;
    }

    public void setId(int id) {
        this.id = id;
    }

    public String getUsername() {
        return username;
    }

    public void setUsername(String username) {
        this.username = username;
    }

    public int getPassword() {
        return password;
    }

    public void setPassword(int password) {
        this.password = password;
    }

    public int getAge() {
        return age;
    }

    public void setAge(int age) {
        this.age = age;
    }

    public String getSex() {
        return sex;
    }

    public void setSex(String sex) {
        this.sex = sex;
    }

    @Override
    public String toString() {
        return "User{" +
                "id=" + id +
                ", username='" + username + '\'' +
                ", password=" + password +
                ", age=" + age +
                ", sex='" + sex + '\'' +
                '}';
    }
}

2、DAO接口
public interface UserMapper {

Object getUserById(int id);
}



3、数据库dbconfig.properties 配置文件：

jdbcUrl=jdbc:db2://***********
driverClass=com.ibm.db2.jcc.DB2Driver
username=********
password=********

4、mybatis的核心配置文件

<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE configuration PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration><!-- 配置 -->
    <properties resource="dbconfig.properties"></properties>
<settings>
    <!--mybatis标准日志-->
    <setting name="logImpl" value="STDOUT_LOGGING"/>
    <!--指定日志输出格式，需配置properties-->
    <!--<setting name="logImpl" value="LOG4J"/>-->
</settings>
    <typeAliases>
        <typeAlias type="com.entity.User" alias="User"/>
        <typeAlias type="com.entity.Book" alias="Book"/>
        <typeAlias type="com.entity.UserHaveMoreBook" alias="UserHaveMoreBook"/>

    </typeAliases>
    <environments default="development"><!-- 配置环境 -->
        <environment id="development"><!-- 环境变量 -->
            <transactionManager  type="JDBC"/><!-- 事务管理器 -->
            <!-- 数据源 -->
            <dataSource type="POOLED">
                <property name="driver" value="${driverClass}"/>
                <property name="url" value="${jdbcUrl}"/>
                <property name="username" value="${user}"/>
                <property name="password" value="${password}"/>
            </dataSource>
        </environment>
    </environments>
    <mappers>
        <mapper resource="com/Dao/UserMapper.xml"/>
        <mapper resource="com/Dao/UserBookMapper.xml"/>
        <mapper resource="com/Dao/UserHaveMoreBookMapper.xml"/>

    </mappers><!-- 映射器  -->
</configuration>



5、DAO接口对应的Mapper文件：
<?xml version="1.0" encoding="UTF-8" ?> <!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">

<mapper namespace="com.springmybatis.dao.UserMapper">

<select id="getUserById" parameterType="_int" resultType="User"> select * from DB2INST.TBL_USER Where id = #{id}

</select>

</mapper>



6、测试

public class test {
    SqlSession sqlSession;
    UserMapper mapper;

    @Before
    public void set(){
         sqlSession = MybatisUtils.getSqlSession();
         mapper = sqlSession.getMapper(UserMapper.class);


    }
    @Test
    public void findAllTest(){
        User user = mapper.getUserById(30027);
        System.out.printf("结果："+user);

    }

    @After
    public void end(){
        sqlSession.close();
    }
}
