0.5 Elasticsearch-一键搭建：Docker Compose 起 3 节点集群

目标：一条命令 docker compose up -d 拉起 3 个 Elasticsearch 节点，自动发现、自动选主、带安全认证、带 Kibana 可视化，5 分钟内可索引第一条文档。
环境：Docker ≥ 20.10、Docker Compose ≥ v2、宿主机 8 GB+ 空闲内存。
仓库：完整文件已上传至 https://github.com/yourname/es-3node，可直接 clone 使用。

1. 最终效果

$ git clone https://github.com/yourname/es-3node.git && cd es-3node
$ docker compose up -d
Creating network "es-3node_esnet" with driver "bridge"
Creating es01 ... done
Creating es02 ... done
Creating es03 ... done
Creating kibana ... done
$ curl -k -u elastic:changeme https://localhost:9200/_cat/nodes
es03  192.168.0.4  8 96 0.12 0.08 0.05 cdfhilmrstw * MASTER
es02  192.168.0.3  8 96 0.11 0.07 0.04 cdfhilmrstw -
es01  192.168.0.2  8 96 0.10 0.06 0.03 cdfhilmrstw -

打开 https://localhost:5601，输入同一套账号即可进入 Kibana。

2. 目录结构

es-3node/
├── docker-compose.yml
├── .env
├── certs/
│   └── create-certs.yml        # 一次性生成 TLS 证书
└── config/
    ├── elasticsearch.yml       # 通用 ES 配置模板
    └── kibana.yml

3. 核心 compose 文件（docker-compose.yml）

version: "3.9"

services:
  setup:
    image: docker.elastic.co/elasticsearch/elasticsearch:8.15.3
    volumes:
      - ./certs:/usr/share/elasticsearch/config/certs
    command: >
      bash -c '
        if [ ! -f /usr/share/elasticsearch/config/certs/ca/ca.crt ]; then
          echo ">> 生成 CA 及节点证书..."
          bin/elasticsearch-certutil ca --silent --pem -out config/certs/ca/ca.zip;
          unzip -q config/certs/ca/ca.zip -d config/certs/ca;
          bin/elasticsearch-certutil cert --silent --pem \
            -out config/certs/certs.zip --ca-cert config/certs/ca/ca.crt --ca-key config/certs/ca/ca.key \
            --dns es01,es02,es03,localhost --ip 127.0.0.1;
          unzip -q config/certs/certs.zip -d config/certs;
        fi;
        chown -R 1000:0 /usr/share/elasticsearch/config/certs
      '
    user: "0"

  es01:
    depends_on: ["setup"]
    image: docker.elastic.co/elasticsearch/elasticsearch:8.15.3
    container_name: es01
    environment:
      - node.name=es01
      - cluster.name=es-docker
      - discovery.seed_hosts=es02,es03
      - cluster.initial_master_nodes=es01,es02,es03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms2g -Xmx2g"
      - xpack.security.enabled=true
      - xpack.security.http.ssl.enabled=true
      - xpack.security.transport.ssl.enabled=true
      - xpack.security.http.ssl.key=certs/es01/es01.key
      - xpack.security.http.ssl.certificate=certs/es01/es01.crt
      - xpack.security.transport.ssl.key=certs/es01/es01.key
      - xpack.security.transport.ssl.certificate=certs/es01/es01.crt
      - xpack.security.transport.ssl.certificate_authorities=certs/ca/ca.crt
      - xpack.security.http.ssl.certificate_authorities=certs/ca/ca.crt
    ulimits:
      memlock:
        soft: -1
        hard: -1
    volumes:
      - esdata01:/usr/share/elasticsearch/data
      - ./certs:/usr/share/elasticsearch/config/certs:ro
      - ./config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml:ro
    ports:
      - 9200:9200
    networks:
      - esnet
    healthcheck:
      test: ["CMD-SHELL", "curl -k -u elastic:${ELASTIC_PASSWORD} https://localhost:9200 | grep -q cluster_uuid"]
      interval: 30s
      timeout: 10s
      retries: 5

  es02:
    depends_on: ["es01"]
    image: docker.elastic.co/elasticsearch/elasticsearch:8.15.3
    container_name: es02
    environment:
      - node.name=es02
      - cluster.name=es-docker
      - discovery.seed_hosts=es01,es03
      - cluster.initial_master_nodes=es01,es02,es03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms2g -Xmx2g"
      - xpack.security.enabled=true
      - xpack.security.http.ssl.enabled=true
      - xpack.security.transport.ssl.enabled=true
      - xpack.security.http.ssl.key=certs/es02/es02.key
      - xpack.security.http.ssl.certificate=certs/es02/es02.crt
      - xpack.security.transport.ssl.key=certs/es02/es02.key
      - xpack.security.transport.ssl.certificate=certs/es02/es02.crt
      - xpack.security.transport.ssl.certificate_authorities=certs/ca/ca.crt
      - xpack.security.http.ssl.certificate_authorities=certs/ca/ca.crt
    ulimits:
      memlock:
        soft: -1
        hard: -1
    volumes:
      - esdata02:/usr/share/elasticsearch/data
      - ./certs:/usr/share/elasticsearch/config/certs:ro
      - ./config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml:ro
    networks:
      - esnet

  es03:
    depends_on: ["es01"]
    image: docker.elastic.co/elasticsearch/elasticsearch:8.15.3
    container_name: es03
    environment:
      - node.name=es03
      - cluster.name=es-docker
      - discovery.seed_hosts=es01,es02
      - cluster.initial_master_nodes=es01,es02,es03
      - bootstrap.memory_lock=true
      - "ES_JAVA_OPTS=-Xms2g -Xmx2g"
      - xpack.security.enabled=true
      - xpack.security.http.ssl.enabled=true
      - xpack.security.transport.ssl.enabled=true
      - xpack.security.http.ssl.key=certs/es03/es03.key
      - xpack.security.http.ssl.certificate=certs/es03/es03.crt
      - xpack.security.transport.ssl.key=certs/es03/es03.key
      - xpack.security.transport.ssl.certificate=certs/es03/es03.crt
      - xpack.security.transport.ssl.certificate_authorities=certs/ca/ca.crt
      - xpack.security.http.ssl.certificate_authorities=certs/ca/ca.crt
    ulimits:
      memlock:
        soft: -1
        hard: -1
    volumes:
      - esdata03:/usr/share/elasticsearch/data
      - ./certs:/usr/share/elasticsearch/config/certs:ro
      - ./config/elasticsearch.yml:/usr/share/elasticsearch/config/elasticsearch.yml:ro
    networks:
      - esnet

  kibana:
    depends_on: ["es01"]
    image: docker.elastic.co/kibana/kibana:8.15.3
    container_name: kibana
    ports:
      - 5601:5601
    environment:
      - ELASTICSEARCH_HOSTS=["https://es01:9200","https://es02:9200","https://es03:9200"]
      - ELASTICSEARCH_USERNAME=kibana_system
      - ELASTICSEARCH_PASSWORD=${KIBANA_PASSWORD}
      - ELASTICSEARCH_SSL_CERTIFICATEAUTHORITIES=config/certs/ca/ca.crt
    volumes:
      - ./certs:/usr/share/kibana/config/certs:ro
      - ./config/kibana.yml:/usr/share/kibana/config/kibana.yml:ro
    networks:
      - esnet

volumes:
  esdata01:
  esdata02:
  esdata03:

networks:
  esnet:
    driver: bridge

4. 环境变量（.env）

# 修改成你自己的强密码
ELASTIC_PASSWORD=changeme
KIBANA_PASSWORD=changeme

5. 通用 elasticsearch.yml

cluster.routing.allocation.disk.threshold_enabled: true
cluster.routing.allocation.disk.watermark.low: 85%
cluster.routing.allocation.disk.watermark.high: 90%
action.auto_create_index: .monitoring*,.watches,.triggered_watches,.watcher-history*,.ml*

6. 启动流程拆解

setup 容器最先运行，自动生成 CA、节点证书，并统一文件夹权限。
es01 等待 setup 成功，绑定 9200，成为第一个主候选。
es02/es03 通过 discovery.seed_hosts 找到 es01，加入集群。
三个节点均通过 TLS 加密 9200（HTTP）和 9300（Transport）。
Kibana 使用内置 kibana_system 用户连接任意节点，默认读取 /api/status 做健康检查。

7. 常见问题速查

现象	原因	解决
`memory locking requested for elasticsearch process but memory is not locked`	`bootstrap.memory_lock=true` 未生效	宿主机执行 `sysctl -w vm.swappiness=1` 并添加 `ulimits.memlock`
`max virtual memory areas vm.max_map_count [65530] is too low`	内核参数不足	`echo "vm.max_map_count=262144" >> /etc/sysctl.conf && sysctl -p`
节点无法发现	证书 DNS/IP 与 compose 名不一致	检查证书生成命令中的 `--dns/--ip` 参数
Kibana 报 `Unable to connect to Elasticsearch`	密码错误或 CA 不匹配	确认 `.env` 与 `kibana_system` 密码一致，并挂载 ca.crt

8. 验证集群

# 查看节点
curl -k -u elastic:changeme https://localhost:9200/_cat/nodes?v

# 创建索引
curl -k -u elastic:changeme -X PUT https://localhost:9200/shop-order-000001

# 写入文档
curl -k -u elastic:changeme -X POST https://localhost:9200/shop-order-000001/_doc \
  -H 'Content-Type: application/json' -d'
{"title":"MacBook Pro","price":15999,"@timestamp":"'"$(date -u +%Y-%m-%dT%H:%M:%S)"'"}'

# 搜索
curl -k -u elastic:changeme https://localhost:9200/shop-order-000001/_search?q=title:MacBook

9. 清理环境

docker compose down -v       # 停容器并删卷
rm -rf certs/*.crt certs/*.key certs/ca/*   # 若需重新生成证书

10. 下一步

修改 ELASTIC_PASSWORD 并启用内置 LDAP/AD 集成；
通过 index.lifecycle_policy 配置 30 天热→温→冷→删除；
使用 Fleet 接入 Elastic Agent，统一收集宿主机日志与指标；
把 compose 文件拆成 Swarm stack，跨多机部署 6 节点（3 master + 3 data）。

至此，一条命令即可拥有本地高可用 Elasticsearch 8 集群，开发、测试、演示开箱即用。
