android自定义dialog弹出框、透明背景

Dialog是android开发过程中最常用到的组件之一，它包括以下几种类型：

1. 警告对话框：Alertialog
2. 进度对话框：ProgressDialog
3. 日期选择对话框：DatePickerDialog
4. 时间选择对话框：TimePickerDialog
5. 自定义对话框：从Dialog继承

Dialog的创建方式有两种：

一是直接new一个Dialog对象，然后调用Dialog对象的show和dismiss方法来控制对话框的显示和隐藏。

二是在Activity的onCreateDialog(int id)方法中创建Dialog对象并返回，然后调用Activty的showDialog(int id)和dismissDialog(int id)来显示和隐藏对话框。

区别在于通过第二种方式创建的对话框会继承Activity的属性，比如获得Activity的menu事件等。

-------------------------------------------------------------------------------------------------------------------------------------------------------------------

CondimentDialog.java

public class CondimentDialog extends Dialog{

 private Context mContext;
 private Button okButton;

 public CondimentDialog(Context context, int theme) {
  super(context,theme);
  mContext = context;
  requestWindowFeature(Window.FEATURE_NO_TITLE);
  setContentView(R.layout.dialog);


  LayoutParams params = getWindow().getAttributes();
  params.height = LayoutParams.WRAP_CONTENT;
  params.width = LayoutParams.WRAP_CONTENT;
  getWindow().setAttributes((android.view.WindowManager.LayoutParams) params);

  okButton = (Button)findViewById(R.id.btnOK);
  okButton.setText("shuosdhsfsdfsdf");
  okButton.setOnClickListener(new Button.OnClickListener(){

   public void onClick(View v) {
   // TODO Auto-generated method stub
    Log.e("dialog dismiss","dismiss+++++++++++++++++++++++++++");
        dismiss();

   } }
  );

 }

 protected void onStop() {
  Log.e("dialog onStop","dialog onStop+++++++++++++++++++++++++++");
  }

}

TestAdroidtbActivity.java



public class TestAdroidtbActivity extends Activity {
    /** Called when the activity is first created. */

 private TextView textView;
 private Button button_ok;
 private Context mContext;

    @Override
    public void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.main);


        textView = (TextView)this.findViewById(R.id.itemName);
        button_ok = (Button)this.findViewById(R.id.btnOK);

        button_ok.setOnClickListener(new OnClickListener() {

   @Override
   public void onClick(View v) {
    // TODO Auto-generated method stub
    Log.e("activity", "onclick....");
    CondimentDialog dialog = new CondimentDialog(TestAdroidtbActivity.this,R.style.dialog);
    dialog.setCanceledOnTouchOutside(false);
    dialog.show();
   }
  });

    }

}

main.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
 android:id="@+id/relmain"
    android:layout_width="200dp"
    android:layout_height="200dp"
    android:orientation="vertical"
    android:background="@color/tb">

 <TextView
  android:id="@+id/itemName"
     android:layout_height="wrap_content"
  android:layout_width="fill_parent" android:textSize="20dp"
  android:gravity="center"
  android:layout_marginTop="50px"
  android:layout_marginLeft="8px"
  android:layout_marginRight="8px"
  android:text="弹出对话框"/>

 <Button
     android:id="@+id/btnOK"
     android:text="ok"
     android:layout_height="wrap_content"
     android:layout_width="wrap_content"
     android:gravity="center"
     android:layout_marginTop="80px"
  android:layout_marginLeft="15px"/>

</RelativeLayout>

dialog.xml



<?xml version="1.0" encoding="utf-8"?>
<LinearLayout
  xmlns:android="http://schemas.android.com/apk/res/android"
  android:orientation="horizontal"
  android:layout_width="819px"
  android:layout_height="483px"
  android:background="@drawable/pig">

    <Button
     android:id="@+id/btnOK"
     android:text="ok"
     android:layout_height="wrap_content"
     android:layout_width="wrap_content"
     android:layout_gravity="center_vertical"
  android:layout_marginTop="180px"
  android:layout_marginLeft="300px"/>

</LinearLayout>

 styles.xml

 <?xml version="1.0" encoding="utf-8"?>
<resources>
 <style name="Transparent">
  <item name="android:windowBackground">@color/transparent_background</item>
     <item name="android:windowNoTitle">true</item>
 </style>

    <style name="dialog" parent="@android:style/Theme.Dialog">
        <item name="android:windowFrame">@null</item><!--边框-->
        <item name="android:windowIsFloating">true</item><!--是否浮现在activity之上-->
        <item name="android:windowIsTranslucent">false</item><!--半透明-->
        <item name="android:windowNoTitle">true</item><!--无标题-->
        <item name="android:windowBackground">@color/transparent</item><!--背景透明-->
        <item name="android:backgroundDimEnabled">false</item><!--模糊-->
    </style>
</resources>

color.xml

<?xml version="1.0" encoding="utf-8"?>
<resources>
 <color name="transparent_background">#880000AA</color>
 <color name="tb">#FFF000</color>
 <color name="transparent">#00FFFFFF</color>
</resources>
