本文将详细讲解如何在SpringBoot项目中整合Ehcache进行缓存管理，包括创建项目、修改pom.xml、配置ehcache.xml、更新application.properties、启用缓存注解、实现业务逻辑以及编写测试用例。

摘要生成于 C知道，由 DeepSeek-R1 满血版支持，前往体验 >

一创建项目（23-spring-boot-ehcache:复制22-spring-boot-jpa）

二修改pom.xml文件

<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
	xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
	<modelVersion>4.0.0</modelVersion>
	<parent>
		<groupId>org.springframework.boot</groupId>
		<artifactId>spring-boot-starter-parent</artifactId>
		<version>2.1.3.RELEASE</version>
	</parent>
	<groupId>com.bjsxt</groupId>
	<artifactId>23-spring-boot-ehcache</artifactId>
	<version>0.0.1-SNAPSHOT</version>

	<properties>
		<java.version>1.8</java.version>
	</properties>

	<dependencies>
		<!-- springboot的web启动器 -->
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-web</artifactId>
		</dependency>
		<!-- springboot的thymeleaf启动器 -->
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-thymeleaf</artifactId>
		</dependency>
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-data-jpa</artifactId>
		</dependency>
		<!-- mysql数据库驱动 -->
		<dependency>
			<groupId>mysql</groupId>
			<artifactId>mysql-connector-java</artifactId>
		</dependency>
		<!-- druid数据库连接池 -->
		<dependency>
			<groupId>com.alibaba</groupId>
			<artifactId>druid</artifactId>
			<version>1.1.13</version>
		</dependency>
		<!-- 添加junit相关jar包 -->
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-test</artifactId>
		</dependency>
		<!-- spring boot 缓存支持启动器 -->
		<dependency>
			<groupId>org.springframework.boot</groupId>
			<artifactId>spring-boot-starter-cache</artifactId>
		</dependency>

		<!-- ehcache -->
		<dependency>
			<groupId>net.sf.ehcache</groupId>
			<artifactId>ehcache</artifactId>
		</dependency>
	</dependencies>
</project>

三创建Ehcache的配置文件（ehcache.xml[src/main/resources/ehcache.xml]）

复制如下文件内容到ehcache.xml，去掉注释：

<ehcache xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="../config/ehcache.xsd">
    <diskStore path="java.io.tmpdir"/>
    <!-- defaultCache:echcache的默认缓存策略 -->
    <defaultCache
            maxElementsInMemory="10000"
            eternal="false"
            timeToIdleSeconds="120"
            timeToLiveSeconds="120"
            maxElementsOnDisk="10000000"
            diskExpiryThreadIntervalSeconds="120"
            memoryStoreEvictionPolicy="LRU">
        <persistence strategy="localTempSwap"/>
    </defaultCache>

    <!-- 自定义缓存策略,name不能重复 -->
    <cache name="users"
            maxElementsInMemory="10000"
            eternal="false"
            timeToIdleSeconds="120"
            timeToLiveSeconds="120"
            maxElementsOnDisk="10000000"
            diskExpiryThreadIntervalSeconds="120"
            memoryStoreEvictionPolicy="LRU">
        <persistence strategy="localTempSwap"/>
    </cache>
</ehcache>

四修改application.properties文件，添加spring.cache.ehcache.config=ehcache.xml配置

#配置数据库相关信息
spring.datasource.driverClassName=com.mysql.cj.jdbc.Driver
spring.datasource.url=jdbc:mysql://localhost:3306/test?useUnicode=true&characterEncoding=utf-8&useSSL=false&serverTimezone=GMT
spring.datasource.username=root
spring.datasource.password=123456
#配置数据库连接池信息
spring.datasource.type=com.alibaba.druid.pool.DruidDataSource
#jpa相关配置
spring.jpa.hibernate.ddl-auto=update
spring.jpa.show-sql=true
#配置ehcache配置
#这样写不行，或报异常spring.cache.ehcache.config=ehcache.xml
spring.cache.ehcache.config=classpath:ehcache.xml

五修改启动类，添加@EnableCaching注解

package com.bjsxt;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cache.annotation.EnableCaching;

@SpringBootApplication
@EnableCaching
public class App {
	public static void main(String[] args) {
		SpringApplication.run(App.class, args);
	}
}

六编写业务层

package com.bjsxt.service;

import java.util.List;

import org.springframework.data.domain.Page;
import org.springframework.data.domain.Pageable;

import com.bjsxt.pojo.Users;

public interface UsersService {
	List<Users> findUserAll();

	Users findUserById(Integer id);

	Page<Users> findUserByPage(Pageable pageable);

	void saveUsers(Users user);
}

package com.bjsxt.service.impl;

import java.util.List;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.cache.annotation.Cacheable;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.Pageable;
import org.springframework.stereotype.Service;

import com.bjsxt.dao.UsersRepository;
import com.bjsxt.pojo.Users;
import com.bjsxt.service.UsersService;

@Service
public class UsersServiceImpl implements UsersService{

	@Autowired
	private UsersRepository usersRepository;

	@Override
	public List<Users> findUserAll() {
		return usersRepository.findAll();
	}

	@Override
	// @Cacheable:对当前查询的对象做缓存处理 value指定ehcache.xml中的哪个配置
	@Cacheable(value="users")
	public Users findUserById(Integer id) {
		return usersRepository.findById(id).get();
	}

	@Override
	public Page<Users> findUserByPage(Pageable pageable) {
		return usersRepository.findAll(pageable);
	}

	@Override
	public void saveUsers(Users user) {
		usersRepository.save(user);
	}
}

七编写测试类

package com.bjsxt.service;

import static org.junit.Assert.fail;

import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.test.context.junit4.SpringJUnit4ClassRunner;

import com.bjsxt.App;
import com.bjsxt.pojo.Users;

@RunWith(SpringJUnit4ClassRunner.class)
@SpringBootTest(classes=App.class)
public class UsersServiceTest {

	@Autowired
	private UsersService usersService;

	@Test
	public void testFindUserAll() {
		fail("Not yet implemented");
	}

	/**
	 	2019-04-12 17:58:52.047  INFO 10904 --- [           main] com.bjsxt.service.UsersServiceTest       : Started UsersServiceTest in 15.43 seconds (JVM running for 18.177)
		Hibernate: select users0_.id as id1_3_0_, users0_.address as address2_3_0_, users0_.age as age3_3_0_, users0_.name as name4_3_0_, users0_.role_id as role_id5_3_0_, roles1_.role_id as role_id1_1_1_, roles1_.role_name as role_nam2_1_1_, menus2_.role_id as role_id1_2_2_, menus3_.menus_id as menus_id2_2_2_, menus3_.menus_id as menus_id1_0_3_, menus3_.father_id as father_i2_0_3_, menus3_.menus_name as menus_na3_0_3_, menus3_.menus_url as menus_ur4_0_3_ from t_users users0_ left outer join t_roles roles1_ on users0_.role_id=roles1_.role_id left outer join t_roles_menus menus2_ on roles1_.role_id=menus2_.role_id left outer join t_menus menus3_ on menus2_.menus_id=menus3_.menus_id where users0_.id=?
		Users [id=1, name=guozi44, age=18, address=地球]
		Hibernate: select users0_.id as id1_3_0_, users0_.address as address2_3_0_, users0_.age as age3_3_0_, users0_.name as name4_3_0_, users0_.role_id as role_id5_3_0_, roles1_.role_id as role_id1_1_1_, roles1_.role_name as role_nam2_1_1_, menus2_.role_id as role_id1_2_2_, menus3_.menus_id as menus_id2_2_2_, menus3_.menus_id as menus_id1_0_3_, menus3_.father_id as father_i2_0_3_, menus3_.menus_name as menus_na3_0_3_, menus3_.menus_url as menus_ur4_0_3_ from t_users users0_ left outer join t_roles roles1_ on users0_.role_id=roles1_.role_id left outer join t_roles_menus menus2_ on roles1_.role_id=menus2_.role_id left outer join t_menus menus3_ on menus2_.menus_id=menus3_.menus_id where users0_.id=?
		Users [id=1, name=guozi44, age=18, address=地球]
		2019-04-12 17:58:52.573  INFO 10904 --- [       Thread-4] o.s.s.concurrent.ThreadPoolTaskExecutor  : Shutting down ExecutorService 'applicationTaskExecutor'
		从以上结果可看出，会执行两次sql
		解决：在UsersServiceImpl.findUserById方法添加@Cacheable(value="users")注解
		二次改后：
		Hibernate: select users0_.id as id1_3_0_, users0_.address as address2_3_0_, users0_.age as age3_3_0_, users0_.name as name4_3_0_, users0_.role_id as role_id5_3_0_, roles1_.role_id as role_id1_1_1_, roles1_.role_name as role_nam2_1_1_, menus2_.role_id as role_id1_2_2_, menus3_.menus_id as menus_id2_2_2_, menus3_.menus_id as menus_id1_0_3_, menus3_.father_id as father_i2_0_3_, menus3_.menus_name as menus_na3_0_3_, menus3_.menus_url as menus_ur4_0_3_ from t_users users0_ left outer join t_roles roles1_ on users0_.role_id=roles1_.role_id left outer join t_roles_menus menus2_ on roles1_.role_id=menus2_.role_id left outer join t_menus menus3_ on menus2_.menus_id=menus3_.menus_id where users0_.id=?
		Users [id=1, name=guozi44, age=18, address=地球]
		Users [id=1, name=guozi44, age=18, address=地球]
		只会查一次，两次输出结果一致，但有异常，异常信息为：java.io.NotSerializableException: com.bjsxt.pojo.Users
		解决：Users实现Serializable接口即可
	 */
	@Test
	public void testFindUserById() {
		// 第一次查询
		Users users = usersService.findUserById(1);
		System.out.println(users);

		// 第二次查询
		Users users2 = usersService.findUserById(1);
		System.out.println(users2);
	}

	@Test
	public void testFindUserByPage() {
		fail("Not yet implemented");
	}

	@Test
	public void testSaveUsers() {
		fail("Not yet implemented");
	}

}
