Flume 常用拦截器

Flume 拦截器

时间戳拦截器
flume-timestamp.conf

#1.定义agent名， source、channel、sink的名称
a4.sources = r1
a4.channels = c1
a4.sinks = k1

#2.具体定义source
a4.sources.r1.type = spooldir
a4.sources.r1.spoolDir = /opt/wind

#定义拦截器，为文件最后添加时间戳
a4.sources.r1.interceptors = timestamp
a4.sources.r1.interceptors.timestamp.type = org.apache.flume.interceptor.TimestampInterceptor$Builder

#具体定义channel
a4.channels.c1.type = memory
a4.channels.c1.capacity = 10000
a4.channels.c1.transactionCapacity = 100


#具体定义sink
a4.sinks.k1.type = hdfs
a4.sinks.k1.hdfs.path = hdfs://bigdata111:9000/flume-interceptors/%H
a4.sinks.k1.hdfs.filePrefix = events-
a4.sinks.k1.hdfs.fileType = DataStream

#不按照条数生成文件
a4.sinks.k1.hdfs.rollCount = 0
#HDFS上的文件达到128M时生成一个文件
a4.sinks.k1.hdfs.rollSize = 134217728
#HDFS上的文件达到60秒生成一个文件
a4.sinks.k1.hdfs.rollInterval = 60

#组装source、channel、sink
a4.sources.r1.channels = c1
a4.sinks.k1.channel = c1

启动命令

/opt/module/flume-1.8.0/bin/flume-ng agent -n a4 \
-f /opt/module/flume-1.8.0/myconf/flume-timestamp.conf \
-c /opt/module/flume-1.8.0/conf \
-Dflume.root.logger=INFO,console

主机名拦截器
flume-host.conf

#1.定义agent
a1.sources= r1
a1.sinks = k1
a1.channels = c1

#2.定义source
a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind
#拦截器
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = host

#参数为true时用IP192.168.1.111，参数为false时用主机名，默认为true
a1.sources.r1.interceptors.i1.useIP = false
a1.sources.r1.interceptors.i1.hostHeader = agentHost

 #3.定义sinks
a1.sinks.k1.type=hdfs
a1.sinks.k1.hdfs.path = hdfs://bigdata111:9000/flumehost/%{agentHost}
a1.sinks.k1.hdfs.filePrefix = plus_%{agentHost}
#往生成的文件加后缀名.log
a1.sinks.k1.hdfs.fileSuffix = .log
a1.sinks.k1.hdfs.fileType = DataStream
a1.sinks.k1.hdfs.writeFormat = Text
a1.sinks.k1.hdfs.rollInterval = 10
a1.sinks.k1.hdfs.useLocalTimeStamp = true

a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

UUID拦截器
flume-uuid.conf

a1.sources = r1
a1.sinks = k1
a1.channels = c1

a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind
a1.sources.r1.interceptors = i1
#type的参数不能写成uuid，得写具体，否则找不到类
a1.sources.r1.interceptors.i1.type = org.apache.flume.sink.solr.morphline.UUIDInterceptor$Builder
#如果UUID头已经存在,它应该保存
a1.sources.r1.interceptors.i1.preserveExisting = true
a1.sources.r1.interceptors.i1.prefix = UUID_

#如果sink类型改为HDFS，那么在HDFS的文本中没有headers的信息数据
a1.sinks.k1.type = logger

a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

查询替换拦截器
flume-search_replace.conf

#1 agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1

#2 source
a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = search_replace

#遇到数字改成wind，A123会替换为Awind
a1.sources.r1.interceptors.i1.searchPattern = [0-9]+
a1.sources.r1.interceptors.i1.replaceString = wind
a1.sources.r1.interceptors.i1.charset = UTF-8

#3 sink
a1.sinks.k1.type = logger

#4 Chanel
a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

#5 bind
a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

正则过滤拦截器
flume-filter.conf

#1 agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1

#2 source
a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = regex_filter
a1.sources.r1.interceptors.i1.regex = ^A.*
#如果excludeEvents设为false,表示过滤掉不是以A开头的events。如果excludeEvents设为true，则表示过滤掉以A开头的events。
a1.sources.r1.interceptors.i1.excludeEvents = true

a1.sinks.k1.type = logger

a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

正则抽取拦截器
flume-extractor.conf

#1 agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1

#2 source
a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = regex_extractor
# hostname is bigdata111 ip is 192.168.20.111
a1.sources.r1.interceptors.i1.regex = hostname is (.*?) ip is (.*)
a1.sources.r1.interceptors.i1.serializers = s1 s2
#hostname（自定义）= (.*?)->bigdata111
a1.sources.r1.interceptors.i1.serializers.s1.name = hostname
#ip（自定义） = (.*)->192.168.20.111
a1.sources.r1.interceptors.i1.serializers.s2.name = ip

a1.sinks.k1.type = logger

a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1

自定义拦截器
字母小写变大写
第一步：添加 flume 依赖

<dependencies>
        <!-- flume核心依赖 -->
        <dependency>
            <groupId>org.apache.flume</groupId>
            <artifactId>flume-ng-core</artifactId>
            <version>1.8.0</version>
        </dependency>
    </dependencies>
    <build>
        <plugins>
            <!-- 打包插件 -->
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-jar-plugin</artifactId>
                <version>2.4</version>
                <configuration>
                    <archive>
                        <manifest>
                            <addClasspath>true</addClasspath>
                            <classpathPrefix>lib/</classpathPrefix>
                            <mainClass></mainClass>
                        </manifest>
                    </archive>
                </configuration>
            </plugin>
            <!-- 编译插件 -->
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-compiler-plugin</artifactId>
                <configuration>
                    <source>1.8</source>
                    <target>1.8</target>
                    <encoding>utf-8</encoding>
                </configuration>
            </plugin>
        </plugins>
    </build>

第二步：IDEA 自定义实现拦截器

import org.apache.flume.Context;
import org.apache.flume.Event;
import org.apache.flume.interceptor.Interceptor;

import java.util.ArrayList;
import java.util.List;

public class MyInterceptor implements Interceptor {
    public void initialize() {

    }
    /**
     * 拦截器实现方法
     * @param event 一个事件  封装了一行数据，有header和body（具体的数据）
     * */
    public Event intercept(Event event) {
        //获取带body
        byte[] oldbody = event.getBody();

        //将数据转换为大写
        byte[] bytes = new String(oldbody).toUpperCase().getBytes();

        //将转换后的数据分装成一个event，返回
        event.setBody(bytes);
        return event;
    }

    public List<Event> intercept(List<Event> list) {
        ArrayList<Event> events = new ArrayList<Event>();
        //循环每个事件的数据转换成大写
        for(Event event : list){
            events.add(intercept(event));
        }
        return events;
    }

    public void close() {

    }
    public static class Builder implements Interceptor.Builder{

        public Interceptor build() {
            return new MyInterceptor();
        }

        public void configure(Context context) {

        }
    }
}

创建 flume-myInterceptor.conf

#1 agent
a1.sources = r1
a1.sinks = k1
a1.channels = c1

#2 source
a1.sources.r1.type = exec
a1.sources.r1.channels = c1
a1.sources.r1.command = tail -F /opt/wind

#定义拦截器规则
a1.sources.r1.interceptors = i1
a1.sources.r1.interceptors.i1.type = flume.MyInterceptor$Builder

a1.sinks.k1.type = logger

a1.channels.c1.type = memory
a1.channels.c1.capacity = 1000
a1.channels.c1.transactionCapacity = 100

a1.sources.r1.channels = c1
a1.sinks.k1.channel = c1
