Kubernetes基于helm安装 harbor

之前harbor的安装都是借助docker完成一键安装部署，安装完成之后harbor组件均运行到一台机器上面，本文实践harbor在k8s环境中的部署。

准备工作

根据harbor官方要求：

Kubernetes cluster 1.20+
Helm v3.2.0+

结合ingress-nginx版本要求，建议K8S版本大于1.21.0-0进行实践。

部署一套K8S环境

本文使用的k8s环境如下：

# k8s版本及环境信息
root@master1:~# kubectl get node -o wide
NAME      STATUS   ROLES           AGE   VERSION   INTERNAL-IP    EXTERNAL-IP   OS-IMAGE           KERNEL-VERSION     CONTAINER-RUNTIME
master1   Ready    control-plane   25h   v1.28.2   192.168.0.61   <none>        Ubuntu 24.04 LTS   6.8.0-36-generic   containerd://1.7.12
node1     Ready    <none>          25h   v1.28.2   192.168.0.62   <none>        Ubuntu 24.04 LTS   6.8.0-36-generic   containerd://1.7.12
node2     Ready    <none>          25h   v1.28.2   192.168.0.63   <none>        Ubuntu 24.04 LTS   6.8.0-36-generic   containerd://1.7.12

# 操作系统信息
root@master1:~# cat /etc/issue
Ubuntu 24.04 LTS \n \l

root@master1:~# uname -a
Linux master1 6.8.0-36-generic #36-Ubuntu SMP PREEMPT_DYNAMIC Mon Jun 10 10:49:14 UTC 2024 x86_64 x86_64 x86_64 GNU/Linux

# helm版本
root@master1:~# helm version
version.BuildInfo{
   Version:"v3.15.2", GitCommit:"1a500d5625419a524fdae4b33de351cc4f58ec35", GitTreeState:"clean", GoVersion:"go1.22.4"}

部署openebs用于提供pv

参考我的另外一篇文章部署openebs，《Kubernetes云原生存储解决方案openebs部署实践-3.10.0版本（helm部署）》

本文部署的openebs信息如下：

root@master1:~# helm ls -n openebs
NAME    NAMESPACE       REVISION        UPDATED                                 STATUS          CHART           APP VERSION
openebs openebs         1               2024-07-02 14:38:40.928808834 +0800 CST deployed        openebs-4.0.1   4.0.1
root@master1:~# kubectl get pod -n openebs
NAME                                              READY   STATUS    RESTARTS   AGE
openebs-localpv-provisioner-6b8bff68bd-vmwp7      1/1     Running   0          121m
openebs-lvm-localpv-controller-778b75449c-mmvw6   5/5     Running   0          121m
openebs-lvm-localpv-node-d2trc                    2/2     Running   0          121m
openebs-lvm-localpv-node-md5wh                    2/2     Running   0          121m
openebs-zfs-localpv-controller-6665568c7c-snw4q   5/5     Running   0          121m
openebs-zfs-localpv-node-mc8tv                    2/2     Running   0          121m
openebs-zfs-localpv-node-w6nns                    2/2
