5.如何实现配电柜图标的旋转(如果需要)以及更复杂的动画效果?</think>### Vue2 地图管理页面实现方案
根据需求分析,我们需要实现一个包含地图配置、组织切换和消防设施展示的页面。以下是实现方案:
```vue
<template>
<div class="map-management">
<!-- 组织切换 -->
<div class="org-switch">
<a-select v-model="currentOrg" @change="handleOrgChange">
<a-select-option v-for="org in orgList" :key="org.id" :value="org.id">
{{ org.name }}
</a-select-option>
</a-select>
</div>
<!-- 地图配置操作区 -->
<div class="map-config">
<a-tabs>
<a-tab-pane key="raster" tab="光栅图配置">
<a-upload
name="rasterImage"
:action="uploadUrl"
:beforeUpload="beforeUpload"
:fileList="fileList"
@change="handleUploadChange"
accept="image/jpeg,image/png,image/bmp"
>
<a-button> <a-icon type="upload" /> 上传背景图片 </a-button>
<div slot="tip" class="upload-tip">
支持格式: JPG/PNG/BMP, 最大50MB, 尺寸不超过1亿像素
</div>
</a-upload>
</a-tab-pane>
<a-tab-pane key="facilities" tab="设施配置">
<div class="facility-types">
<div
v-for="facility in facilityTypes"
:key="facility.type"
class="facility-item"
draggable="true"
@dragstart="handleDragStart($event, facility)"
>
<div
class="facility-icon"
:style="{ backgroundColor: facility.color }"
:class="{ 'blink': facility.hasAlarm }"
></div>
<div>{{ facility.name }}</div>
</div>
</div>
</a-tab-pane>
</a-tabs>
</div>
<!-- 地图展示区域 -->
<div
class="map-container"
ref="mapContainer"
@dragover.prevent
@drop="handleDrop"
>
<!-- 背景图片 -->
<img
v-if="currentMap.background"
:src="currentMap.background"
alt="地图背景"
class="map-background"
/>
<!-- 设施展示 -->
<div
v-for="facility in currentMap.facilities"
:key="facility.id"
class="map-facility"
:style="{
left: `${facility.position.x}px`,
top: `${facility.position.y}px`,
backgroundColor: facility.color
}"
:class="{ 'blink': facility.hasAlarm }"
@mouseenter="showFacilityTooltip(facility)"
@mouseleave="hideTooltip"
@click="showFacilityDetail(facility)"
>
<a-tooltip :title="facilityTooltip" :visible="tooltipVisible">
<div class="facility-icon"></div>
</a-tooltip>
</div>
</div>
<!-- 设施详情弹窗 -->
<a-modal
:title="selectedFacility ? selectedFacility.name : '设施详情'"
:visible="facilityDetailVisible"
@cancel="facilityDetailVisible = false"
:footer="null"
>
<facility-detail :facility="selectedFacility" />
</a-modal>
</div>
</template>
<script>
import FacilityDetail from './FacilityDetail.vue';
export default {
components: {
FacilityDetail
},
data() {
return {
currentOrg: null,
orgList: [],
uploadUrl: '/api/map/upload-raster',
fileList: [],
currentMap: {
id: null,
background: null,
facilities: []
},
facilityTypes: [
{ type: 'cabinet', name: '配电柜', color: '#1890ff', hasAlarm: false }
],
draggingFacility: null,
selectedFacility: null,
facilityDetailVisible: false,
tooltipVisible: false,
facilityTooltip: ''
};
},
mounted() {
this.loadOrganizations();
this.loadMapConfig();
},
methods: {
// 加载组织列表
async loadOrganizations() {
try {
const response = await this.$api.get('/api/organizations');
this.orgList = response.data;
if (this.orgList.length > 0) {
this.currentOrg = this.orgList[0].id;
}
} catch (error) {
console.error('加载组织列表失败:', error);
}
},
// 加载地图配置
async loadMapConfig() {
if (!this.currentOrg) return;
try {
const response = await this.$api.get(`/api/map-config?org=${this.currentOrg}`);
this.currentMap = response.data;
} catch (error) {
console.error('加载地图配置失败:', error);
this.currentMap = {
id: null,
background: null,
facilities: []
};
}
},
// 组织切换处理
handleOrgChange() {
this.loadMapConfig();
},
// 上传前校验
beforeUpload(file) {
const isImage = ['image/jpeg', 'image/png', 'image/bmp'].includes(file.type);
const isLt50M = file.size / 1024 / 1024 < 50;
// 检查像素尺寸
return new Promise((resolve) => {
const img = new Image();
img.src = URL.createObjectURL(file);
img.onload = () => {
const pixels = img.width * img.height;
if (pixels > 100000000) {
this.$message.error('图片尺寸不能超过1亿像素');
resolve(false);
} else if (!isImage) {
this.$message.error('只能上传JPG/PNG/BMP格式的图片!');
resolve(false);
} else if (!isLt50M) {
this.$message.error('图片大小不能超过50MB!');
resolve(false);
} else {
resolve(true);
}
};
});
},
// 上传状态变化处理
handleUploadChange(info) {
if (info.file.status === 'done') {
this.$message.success(`${info.file.name} 上传成功`);
this.currentMap.background = info.file.response.url;
} else if (info.file.status === 'error') {
this.$message.error(`${info.file.name} 上传失败`);
}
},
// 开始拖拽设施
handleDragStart(event, facility) {
this.draggingFacility = { ...facility };
event.dataTransfer.setData('text/plain', facility.type);
},
// 放置设施到地图
handleDrop(event) {
event.preventDefault();
if (!this.draggingFacility) return;
const containerRect = this.$refs.mapContainer.getBoundingClientRect();
const x = event.clientX - containerRect.left;
const y = event.clientY - containerRect.top;
const newFacility = {
...this.draggingFacility,
id: Date.now().toString(),
position: { x, y },
hasAlarm: Math.random() > 0.7 // 模拟报警状态
};
this.currentMap.facilities.push(newFacility);
this.saveFacilityPosition(newFacility);
},
// 保存设施位置
async saveFacilityPosition(facility) {
try {
await this.$api.post('/api/facilities', {
mapId: this.currentMap.id,
facility
});
} catch (error) {
console.error('保存设施位置失败:', error);
}
},
// 显示设施提示信息
showFacilityTooltip(facility) {
this.facilityTooltip = `${facility.name} | 电流: ${facility.current || 'N/A'}A`;
this.tooltipVisible = true;
},
// 隐藏提示
hideTooltip() {
this.tooltipVisible = false;
},
// 显示设施详情
showFacilityDetail(facility) {
this.selectedFacility = facility;
this.facilityDetailVisible = true;
}
}
};
</script>
<style scoped>
.map-management {
display: flex;
flex-direction: column;
height: 100vh;
}
.org-switch {
padding: 16px;
background: #f0f2f5;
border-bottom: 1px solid #e8e8e8;
}
.map-config {
padding: 16px;
border-bottom: 1px solid #e8e8e8;
}
.facility-types {
display: flex;
gap: 16px;
}
.facility-item {
cursor: grab;
text-align: center;
}
.facility-icon {
width: 30px;
height: 30px;
border-radius: 50%;
margin: 0 auto 8px;
}
.map-container {
flex: 1;
position: relative;
overflow: hidden;
background-color: #f5f5f5;
}
.map-background {
width: 100%;
height: 100%;
object-fit: contain;
}
.map-facility {
position: absolute;
width: 30px;
height: 30px;
border-radius: 50%;
cursor: pointer;
transform: translate(-50%, -50%);
border: 2px solid white;
box-shadow: 0 2px 8px rgba(0, 0, 0, 0.15);
}
.blink {
animation: blink-animation 1s infinite;
}
@keyframes blink-animation {
0% { opacity: 1; }
50% { opacity: 0.3; }
100% { opacity: 1; }
}
.upload-tip {
margin-top: 8px;
color: #999;
font-size: 12px;
}
</style>
```
### 功能说明
1. **组织切换功能**
- 顶部组织选择器,切换时加载对应组织的地图配置
- 通过API加载组织列表和地图配置数据
2. **地图配置功能**
- 光栅图上传:支持JPG/PNG/BMP格式,50MB限制,1亿像素验证
- 设施配置:提供可拖拽的配电柜图标
3. **地图展示区域**
- 支持背景图片显示
- 拖拽放置配电柜设施
- 设施状态可视化:
- 颜色表示风险等级
- 闪烁动画表示报警状态
- 鼠标悬浮显示名称和电流
- 点击展示配电柜详情
4. **数据管理**
- 设施位置保存到后端
- 组织切换时加载对应配置
### 关键实现细节
1. **图片上传验证**
- 使用`beforeUpload`进行文件类型、大小验证
- 通过Image对象计算像素尺寸
2. **拖拽功能**
- 使用HTML5原生拖拽API
- 计算鼠标在容器内的相对位置
3. **设施状态可视化**
- 通过CSS动画实现闪烁效果
- 使用Ant Design的Tooltip组件显示悬浮信息
4. **响应式设计**
- 使用flex布局适应不同屏幕尺寸
- 背景图object-fit: contain保持比例
### 组件结构
```
MapManagement.vue
├── OrgSelector (组织切换)
├── MapConfigTabs (配置选项卡)
│ ├── RasterUpload (光栅图上传)
│ └── FacilityConfig (设施配置)
├── MapContainer (地图容器)
│ ├── BackgroundImage (背景图)
│ └── FacilityItems (设施图标)
└── FacilityDetailModal (设施详情弹窗)
```
