基于Spring Cloud Gateway的外卖霸王餐API限流熔断与灰度发布实践

背景：外卖霸王餐业务的高并发挑战
外卖霸王餐活动瞬时流量可达平日20倍，传统网关难以支撑。本文基于Spring Cloud Gateway构建弹性网关，实现限流、熔断、灰度三位一体防护体系，核心代码，可直接落地生产。

一、架构总览：三层防线

用户请求 → Spring Cloud Gateway → 限流层（Redis令牌桶）→ 熔断层（Resilience4j）→ 灰度层（Ribbon+Metadata）→ 下游微服务

所有过滤器均注册到cn.juwatech.gateway.filter包，统一配置中心采用Nacos，动态刷新秒级生效。
在这里插入图片描述

二、限流：Redis令牌桶精准控速
目标：单接口QPS不超过3000，超出直接返回429。核心实现：

package cn.juwatech.gateway.filter;

public class RateLimitFilter extends AbstractGatewayFilterFactory<RateLimitFilter.Config> {
    private final RedisScript<Long> script = RedisScript.of(
        "local bucket = KEYS[1] " +
        "local rate = tonumber(ARGV[1]) " +
        "local capacity = tonumber(ARGV[2]) " +
        "local now = tonumber(ARGV[3]) " +
        "local requested = tonumber(ARGV[4]) " +
        "local fill_time = capacity/rate " +
        "local ttl = math.floor(fill_time*2) " +
        "local last = redis.call('HMGET', bucket, 'last', 'tokens') " +
        "local last_tokens = tonumber(last[2]) or capacity " +
        "local last_refreshed = tonumber(last[1]) or now " +
        "local delta = math.max(0, now-last_refreshed) " +
        "local filled_tokens = math.min(capacity, last_tokens+(delta*rate)) " +
        "if filled_tokens < requested then return -1 end " +
        "redis.call('HMSET', bucket, 'last', now, 'tokens', filled_tokens-requested) " +
        "redis.call('EXPIRE', bucket, ttl) " +
        "return filled_tokens-requested", Long.class);

    @Override
    public GatewayFilter apply(Config config) {
        return (exchange, chain) -> {
            String key = "rate:" + exchange.getRequest().getURI().getPath();
            Long remain = stringRedisTemplate.execute(script,
                Collections.singletonList(key),
                String.valueOf(config.rate), String.valueOf(config.capacity),
                String.valueOf(Instant.now().toEpochMilli()), "1");
            if (remain < 0) {
                exchange.getResponse().setStatusCode(HttpStatus.TOO_MANY_REQUESTS);
                return exchange.getResponse().setComplete();
            }
            return chain.filter(exchange);
        };
    }

    public static class Config {
        public int rate = 3000;     // 每秒生成的令牌数
        public int capacity = 6000; // 桶容量
    }
}

在application.yml中针对霸王餐下单接口单独限流：

spring:
  cloud:
    gateway:
      routes:
        - id:霸王餐-order
          uri: lb://baidican-order
          predicates:
            - Path=/api/v1/baidican/order/**
          filters:
            - name: RateLimit
              args:
                rate: 3000
                capacity: 6000

三、熔断：Resilience4j快速失败
目标：错误率超5%或响应时长>P99(800ms)即熔断3s，直接返回兜底文案“活动太火爆，稍后再试”。实现：

package cn.juwatech.gateway.circuit;

@Configuration
public class CircuitConfig {
    @Bean
    public Customizer<Resilience4JCircuitBreakerFactory> defaultCustomizer() {
        return factory -> factory.configureDefault(id ->
            Resilience4JConfigBuilder.of(id)
                .circuitBreakerConfig(CircuitBreakerConfig.custom()
                    .failureRateThreshold(5)
                    .waitDurationInOpenState(Duration.ofSeconds(3))
                    .slidingWindowType(SlidingWindowType.COUNT_BASED)
                    .slidingWindowSize(100)
                    .build())
                .timeLimiterConfig(TimeLimiterConfig.custom()
                    .timeoutDuration(Duration.ofMillis(800))
                    .build())
                .build());
    }
}

在路由级别开启熔断：

filters:
  - name: CircuitBreaker
    args:
      name: baidican-cb
      fallbackUri: forward:/fallback/baidican

兜底接口：

@RestController
@RequestMapping("/fallback")
public class FallbackController {
    @GetMapping("/baidican")
    public Map<String,String> baidicanFallback(){
        return Collections.singletonMap("msg","活动太火爆，稍后再试");
    }
}

四、灰度：Ribbon元数据驱动
需求：新版本v2仅对内部员工手机号开放，其他用户仍访问v1。步骤：

在Nacos给实例打标签：

{"version":"v2","gray":"true"}

自定义GrayLoadBalancer：

package cn.juwatech.gateway.loadbalancer;

public class GrayLoadBalancer implements ReactorServiceInstanceLoadBalancer {
    private final ObjectProvider<ServiceInstanceListSupplier> supplier;
    private final String serviceId;

    public GrayLoadBalancer(ObjectProvider<ServiceInstanceListSupplier> supplier, String serviceId) {
        this.supplier = supplier;
        this.serviceId = serviceId;
    }

    @Override
    public Mono<Response<ServiceInstance>> choose(Request request) {
        return supplier.getIfAvailable().get().next()
            .map(instances -> {
                HttpHeaders headers = ((RequestData) request.getContext()).getHeaders();
                String mobile = headers.getFirst("X-Mobile");
                boolean isEmployee = EmployeeUtils.isEmployee(mobile);
                List<ServiceInstance> filtered = instances.stream()
                    .filter(i -> isEmployee ? "v2".equals(i.getMetadata().get("version"))
                                            : "v1".equals(i.getMetadata().get("version")))
                    .collect(Collectors.toList());
                return new DefaultResponse(filtered.get(ThreadLocalRandom.current().nextInt(filtered.size())));
            });
    }
}

替换默认Rule：

@Bean
public GrayLoadBalancer grayLoadBalancer(Environment env,
                                         LoadBalancerClientFactory clientFactory) {
    String name = env.getProperty(LoadBalancerClientFactory.PROPERTY_NAME);
    return new GrayLoadBalancer(clientFactory.getLazyProvider(name, ServiceInstanceListSupplier.class), name);
}
