IPQ6010+QCN9074/QCN6024 support latest WiFi6, Mesh, 4x4 MUMIMO, 160M spectrum

IPQ6010是款Wi-Fi6芯片,支持802.11ax等技术,结合QCN9074的4x4MU-MIMO与160MHz频谱,提供高速、稳定的数据传输,适用于高负载应用场景。两者结合还支持智能QoS和Mesh网络,确保全屋无缝覆盖。

Everyone is very curious about what kind of wireless performance Qualcomm IPQ6010 and QCN9074 can achieve.

Everyone knows that IPQ6010 is mainly a wifi6 chip for the manufacture of router motherboards. It uses the Krait 4 core processor independently developed by Qualcomm, with a main frequency of up to 2.2 GHz. It is equipped with an Adreno 650 image processor and supports the latest WiFi 6 standard, including 802.11ax, MU-MIMO, OFDMA and 1024 QAM and other technologies, while supporting Bluetooth 5.2 and 802.11ad wireless standards.

The chip also integrates Qualcomm's network acceleration technology, including intelligent QoS (Quality of Service) and traffic management functions, to achieve more stable and faster network connections, while also supporting Mesh network topology to achieve coverage of the entire home.

In addition, IPQ6010 also supports 5G NR cell aggregation technology and 160 MHz spectrum, which can provide higher data transmission rate and is suitable for application scenarios that require high-speed, high-performance network connections, such as VR/AR, 4K/8K video streaming media, cloud games etc.

And many industrial projects will require higher wifi performance. If you want to have wifi6e frequency band to make the project more stable and faster transmission, then you need to use the motherboard and network card together, because the board itself has 2.4G/5G radio , and now there are many moudle chips that can support the wifi6e frequency band. Today we will introduce the QCN9074 chip, which can have a 6e frequency band.

The QCN9074 chip is a 5G baseband processor launched by Qualcomm, which supports multiple 5G frequency bands including millimeter wave and sub-6GHz frequency bands.

How strong is the wireless performance achieved by the combination of IPQ6010+QCN9074?

The combination of Qualcomm IPQ6010 and QCN9074 can achieve high-speed, high-reliability network performance. Among them, IPQ6010 is a chip for routers, supports the latest WiFi 6 standard, can provide high-speed data transmission rate and low-latency network connection, and also supports Bluetooth 5.2 and 802.11ad wireless standards, with wider wireless network coverage and transmission capacity.



The QCN9074 is a high-performance, high-reliability wireless network chip that supports 4x4 MU-MIMO technology and 160 MHz spectrum, which can provide high-speed data transmission and wider wireless coverage. The combination of these two chips can achieve faster data transmission rate and more stable wireless connection, which is suitable for high-load application scenarios, such as multi-player online games, video conferencing, etc.

In addition, the combination of IPQ6010 and QCN9074 also supports Qualcomm's intelligent QoS technology and traffic management functions, which can achieve more stable and faster network connections, and supports Mesh network topology to achieve seamless coverage of the entire home.

In general, the combination of IPQ6010 and QCN9074 can achieve high-performance, high-reliability, and high-efficiency network connections, and is suitable for application scenarios that require high-speed, high-performance network connections.
