Vue骨架屏

平时喜欢逛知乎，一日突然发现手机页面出现如下图景象。

比较好奇在页面未加载出来之前显示的这些是怎么实现的，并且意识到之前用于加载的菊花图貌似渐渐被这种加载模式所取代了。后来才知道这种模式称之为骨架屏。

骨架屏的出现无非也是为了提高性能优化并提高用户体验度。并且这种加载模式相比于菊花图，让用户在界面渲染未完成之前可以提前了解到页面的布局。提高了用户的体验度。

在学习了各个博客主的心得之后，实践操作如下。

1、使用vue-cli脚本架搭建vue项目；

2、进行如下图操作：

3、在项目src目录下创建Skeleton.vue文件，代码如下：

<template>
  <div class="skeleton-wrapper">
    <header class="skeleton-header"></header>
    <section class="skeleton-block">
    </section>
  </div>
</template>

<script>
  export default {
    name: 'skeleton'
  }
</script>

<style scoped>
  .skeleton-header {
    height: 40px;
    background: #1976d2;
    padding:0;
    margin: 0;
    width: 100%;
  }
  .skeleton-block {
    display: flex;
    flex-direction: column;
    padding-top: 8px;
  }

</style>

 4、在src目录下搭建entry-skeleton.js文件，代码如下：

import Vue from 'vue'
import Skeleton from './Skeleton'
export default new Vue({
  components: {
    Skeleton
  },
  template: '<Skeleton />'
})

5、在build文件目录下搭建webpack.skeleton.conf.js文件，代码如下：

'use strict';

const path = require('path')
const merge = require('webpack-merge')
const baseWebpackConfig = require('./webpack.base.conf')
const nodeExternals = require('webpack-node-externals')

function resolve(dir) {
  return path.join(__dirname, dir)
}

module.exports = merge(baseWebpackConfig, {
  target: 'node',
  devtool: false,
  entry: {
    app: resolve('../src/entry-skeleton.js')
  },
  output: Object.assign({}, baseWebpackConfig.output, {
    libraryTarget: 'commonjs2'
  }),
  externals: nodeExternals({
    whitelist: /\.css$/
  }),
  plugins: []
})



6、在webpack.dev.conf.js、webpack.prod.conf.js文件加入如下代码：

const SkeletonWebpackPlugin = require('vue-skeleton-webpack-plugin')
new SkeletonWebpackPlugin({
  webpackConfig: require('./webpack.skeleton.conf'),
  quiet: true
}),

自此，最基础的vue项目骨架屏 就搭建完成，运行项目，将chrome开发者工具中的Network选择如下图：

最终效果如下动图所示，在页面加载渲染未完成之前会出现骨架屏：
