如何设置CUDA Kernel中的grid_size和block_size？

原创

于 2021-12-07 13:53:27 发布 · 2.4k 阅读

7 ·

CC 4.0 BY-SA版权

文章标签：

#java #python #多线程 #数据库 #编程语言

本文探讨了CUDA Kernel中grid_size和block_size的设置，指出block_size应为32的倍数且不大于1024，推荐值为128。grid_size应确保足够的Occupancy，避免tail effect，且不超过GPU的最大grid尺寸。通常，elementwise kernel中，block_size设为128，grid_size满足多wave需求。

撰文 | 柳俊丞

一般而言，我们在代码中会看到使用以下方式启动一个 CUDA kernel：

cuda_kernel<<<grid_size, block_size, 0, stream>>>(...)

cuda_kernel 是 global function 的标识，(...) 中是调用 cuda_kernel 对应的参数，这两者和 C++ 的语法是一样的，而 <<<grid_size, block_size, 0, stream>>> 是 CUDA 对 C++ 的扩展，称之为 Execution Configuration（https://docs.nvidia.com/cuda/cuda-c-programming-guide/index.html#execution-configuration），参考 CUDA C++ Programming Guide (https://docs.nvidia.com/cuda/cuda-c-programming-guide/index.html#abstract，后续简称 Guide ) 中的介绍：

The execution configuration is specified by inserting an expression of the form <<< Dg, Db, Ns, S >>> between the function name and the parenthesized argument list, where:

Dg is of type dim3 (see dim3) and specifies the dimension and size of the grid, such that Dg.x * Dg.y * Dg.z equals the number of blocks being launched;

Db is of type dim3 (see dim3) and specifies the dimension and size of each block, such that Db.x * Db.y * Db.z equals the number of threads per block;

Ns is of type size_t and specifies the number of bytes in shared memory that is dynamically allocated per block for this call in addition to the stati
