【echarts多y轴】通过接口获取参数后渲染echarts多y轴图

如题：准备工作如下：

1. 首选准备好echarts图表的option项

// 接口层获取name,按照一左一右的原则，塞入left right的 position数值
export const yAxisSingle = (name = 'V', position = 'left') => {


  return {


    type: 'value',
    name,
    position,
    alignTicks: true,
    // offset: 80,
    axisLine: {


      show: true,
    },
  }
}
// 每一项的series,需要自己判断yAxisIndex是多少，默认取0
export const seriesSingle = (name, key, data = [], yAxisIndex = 0) => {


  return {


    type: 'line',
    name,
    key,
    data,
    yAxisIndex,
  }
}
// 初始化options总数据项
export const energyAnalysisOper = () => {


  return {


    xAxis: {


      type: 'category',
      data: []
    },
    yAxis: {


      type: 'value'
    }, // 这里应该是数组，但是为了初始化不报错就先用对象展示
    tooltip: {


      trigger: 'axis',
      axisPointer: {


        type: 'cross',
        label: {


          backgroundColor: '#6a7985'
        }
      }
    },
    grid: {


      left: '15%',
      right: '15%',
      // bottom: '23%',
    },
    legend: {


      type: 'scroll',
      x: 'center',
      y: 'bottom',
      data: [],
    },
    dataZoom: [
      {


        type: 'inside'
      },
    ],
    series: [
      // {


      //   type: 'line',
      //   name: i18n.t('plant.powerGeneration'),
      //   key: 'pvTotalEnergys',
      //   data: [],
      // },
    ]
  }
}

 <IEcharts
     v-adaptiveEcharts
     title="energyAnalysisOper"
     chartId="energyAnalysisOper"
     :option="energyAnalysisOper"
 />

// 接口层处理逻辑
getChartsFun(params) {


      this.operaEchartsLoading = true
      getCharts(params).then(res => {


        const {

    success, code, message, data } = res
        if (success || ['200'].includes(String(code))) {


          // energyAnalysisOper, yAxisSingle, seriesSingle,
          // 先取出unitMap，防止以后面计算报错
          const {

    unitMap } = data
          delete data.unitMap
          // 判断是否为空data，如果不是空data
          if (!_.isEmpty(data)) {


            const options = energyAnalysisOper() // 初始化echarts配置
            options.yAxis = [] // yAxis按照数组来匹配
            // 先处理y坐标轴的数据，按照去重规则，相同单位仅用一次
            const yAxisIndexObj = {

   }
            const unitMapFormatter = {

   }
            if(!_.isEmpty(this.yAxisObj)) {


              Object.keys(this.yAxisObj).forEach((key, index) => {


                if (this.yAxisObj[key]) {


                  // 处理y轴配置项，如果是偶数，则放在左侧，否则在右侧
                  const yAxisRow = yAxisSingle(key, index % 2 === 0 ? 'left' : 'right')
                  // 如果不是前两条y轴，再来两条y轴需要增加offset
                  if (index > 1) {


                    yAxisRow.offset = 60
                  }
                  options.yAxis.push(yAxisRow)
                  yAxisIndexObj[key] = index
                }
              })
            }
            // 字典需准备的值：国际化对应，单位, 对应坐标轴index
            Object.keys(data).forEach((key, index) => {


              // 如果当前是第一项，则处理一下横坐标数组，防止逻辑重复运行
              if (!index) {


                options.xAxis.data = Object.keys(data[key]).map(item => item)
              }
              // 设置对应坐标轴的data数据 分别为：国际化语言，key值，对应data数组，对应坐标轴
              options.series.push(seriesSingle(
                  this.checkedKeysFilterObj[key].label,
                  key,
                  Object.values(data[key]),
                  yAxisIndexObj[this.checkedKeysFilterObj[key].unit] || 0,
                  // 0,
                  // unitMap[key],
              )),
              options.legend.data.push(this.checkedKeysFilterObj[key].label)
              unitMapFormatter[this.checkedKeysFilterObj[key].label] = unitMap[key]
            })
            options.tooltip.formatter = function (params) {


              let relVal = ''
              for (var i = 0, l = params.length; i < l; i++) {


                relVal += i ? '<br/>' : ''
                relVal += params[i].marker + "&nbsp;" + params[i].seriesName + '&nbsp;' + params[i].value+ '' + unitMapFormatter[params[i].seriesName]
              }
              return relVal
            }
            this.energyAnalysisOper = options
          }
        }
      }).finally(() => {


        this.operaEchartsLoading = false
      })
    },

// 数据mock
{


    "message": "成功",
    "code": 200,
    "data": {


        "pv1Voltage": {


            "01:55": 9.39,
            "18:50": 83.12,
            "02:25": 71.6,
            "08:05": 59.51,
            "02:20": 2.67,
            "07:35": 44.33,
            "08:00": 36.31,
            "20:10": 2.78,
            "07:30": 53.41,
            "01:50": 53.11,
            "14:15": 35.08,
            "13:45": 1.9,
            "20:05": 1.84,
            "19:25": 60.56,
            "14:10": 22.77,
            "19:20": 67.38,
            "13:40": 26.15,
            "18:55": 19.96,
            "02:15": 92.5,
            "01:45": 20.12,
            "19:30": 7.03,
            "07:25": 67.04,
