15-Prometheus监控Ingress-NGINX_TCP

使用prometheus来监控ingress-nginx

ingress-nginx配置了metrics

通过标签去查看ingress的pod

[root@master01 manifests]# kubectl get pods -n ingress-nginx -l app=ingress-nginx -owide
NAME                             READY   STATUS    RESTARTS   AGE     IP           NODE         NOMINATED NODE   READINESS GATES
nginx-ingress-controller-7rxlt   1/1     Running   0          6m30s   10.1.19.56   10.1.19.56
nginx-ingress-controller-cgsmn   1/1     Running   0          6m30s   10.1.19.55   10.1.19.55
nginx-ingress-controller-kxw97   1/1     Running   0          6m30s   10.1.19.54   10.1.19.54
#分别部署在114 和115机器上 我们要监控这两个pod 的ingress-nginx

删了从建

---
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: ingress-nginx-monitor  #监控名称 也就是prometheus ui页面显示
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
spec:
  selector:   #这个标签要匹配到 被监控监控的标签
    matchLabels:
      app: ingress-nginx
  endpoints:
  - port: metrics  #目标服务上暴露指标的端口名称。
    path: /metrics  #目标服务上暴露指标的 HTTP 路径
    interval: 30s   #监控频率 每隔30s抓取一次
      #  jobLabel: app   #指定应该使用哪个标签来将目标分组为 Prometheus 中的一个作业。在这里，使用 app 标签来标识和分组共享此标签的所有目标为同一作业。
  namespaceSelector: #指定 ServiceMonitor 应监控哪些命名空间。
    matchNames:
    - ingress-nginx  #仅选择 ingress-nginx 命名空间

[root@master01 manifests]# cat /data/aqsc_k8s_yaml/
ingress-nginx/   kube-prometheus/ nfs/             prometheus/
[root@master01 manifests]# cat /data/aqsc_k8s_yaml/ingress-nginx/ingress-nginx.yaml
apiVersion: v1
kind: Namespace
metadata:
  name: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

---

kind: ConfigMap
apiVersion: v1
metadata:
  name: nginx-configuration
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

---
kind: ConfigMap
apiVersion: v1
metadata:
  name: tcp-services
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

---
kind: ConfigMap
apiVersion: v1
metadata:
  name: udp-services
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

---
apiVersion: v1
kind: ServiceAccount
metadata:
  name: nginx-ingress-serviceaccount
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

---
apiVersion: rbac.authorization.k8s.io/v1beta1
kind: ClusterRole
metadata:
  name: nginx-ingress-clusterrole
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
rules:
  - apiGroups:
      - ""
    resources:
      - configmaps
      - endpoints
      - nodes
      - pods
      - secrets
    verbs:
      - list
      - watch
  - apiGroups:
      - ""
    resources:
      - nodes
    verbs:
      - get
  - apiGroups:
      - ""
    resources:
      - services
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - "extensions"
    resources:
      - ingresses
    verbs:
      - get
      - list
      - watch
  - apiGroups:
      - ""
    resources:
      - events
    verbs:
      - create
      - patch
  - apiGroups:
      - "extensions"
    resources:
      - ingresses/status
    verbs:
      - update

---
apiVersion: rbac.authorization.k8s.io/v1beta1
kind: Role
metadata:
  name: nginx-ingress-role
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
rules:
  - apiGroups:
      - ""
    resources:
      - configmaps
      - pods
      - secrets
      - namespaces
    verbs:
      - get
  - apiGroups:
      - ""
    resources:
      - configmaps
    resourceNames:
      # Defaults to "<election-id>-<ingress-class>"
      # Here: "<ingress-controller-leader>-<nginx>"
      # This has to be adapted if you change either parameter
      # when launching the nginx-ingress-controller.
      - "ingress-controller-leader-nginx"
    verbs:
      - get
      - update
  - apiGroups:
      - ""
    resources:
      - configmaps
    verbs:
      - create
  - apiGroups:
      - ""
    resources:
      - endpoints
    verbs:
      - get

---
apiVersion: rbac.authorization.k8s.io/v1beta1
kind: RoleBinding
metadata:
  name: nginx-ingress-role-nisa-binding
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: nginx-ingress-role
subjects:
  - kind: ServiceAccount
    name: nginx-ingress-serviceaccount
    namespace: ingress-nginx

---
apiVersion: rbac.authorization.k8s.io/v1beta1
kind: ClusterRoleBinding
metadata:
  name: nginx-ingress-clusterrole-nisa-binding
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: nginx-ingress-clusterrole
subjects:
  - kind: ServiceAccount
    name: nginx-ingress-serviceaccount
    namespace: ingress-nginx

---

apiVersion: apps/v1
kind: DaemonSet
metadata:
  name: nginx-ingress-controller
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx
spec:
  selector:
    matchLabels:
      app.kubernetes.io/name: ingress-nginx
      app.kubernetes.io/part-of: ingress-nginx
      app: ingress-nginx
  template:
    metadata:
      labels:
        app: ingress-nginx
        app.kubernetes.io/name: ingress-nginx
        app.kubernetes.io/part-of: ingress-nginx
      annotations:
        prometheus.io/port: "10254"
        prometheus.io/scrape: "true"
    spec:

      hostNetwork: true
      serviceAccountName: nginx-ingress-serviceaccount
      containers:
        - name: nginx-ingress-controller
          #image: siriuszg/nginx-ingress-controller:0.20.0
          image: images.aqsc.com/siriuszg/nginx-ingress-controller:0.20.0
          args:
            - /nginx-ingress-controller
            - --configmap=$(POD_NAMESPACE)/nginx-configuration
            - --tcp-services-configmap=$(POD_NAMESPACE)/tcp-services
            - --udp-services-configmap=$(POD_NAMESPACE)/udp-services
            - --publish-service=$(POD_NAMESPACE)/ingress-nginx
            - --annotations-prefix=nginx.ingress.kubernetes.io
          securityContext:
            allowPrivilegeEscalation: true
            capabilities:
              drop:
                - ALL
              add:
                - NET_BIND_SERVICE
            # www-data -> 33
            runAsUser: 33
          env:
            - name: POD_NAME
              valueFrom:
                fieldRef:
                  fieldPath: metadata.name
            - name: POD_NAMESPACE
              valueFrom:
                fieldRef:
                  fieldPath: metadata.namespace
          ports:
            - name: http
              containerPort: 80
            - name: https
              containerPort: 443
            - name: metrics
              containerPort: 10254
          livenessProbe:
            failureThreshold: 3
            httpGet:
              path: /healthz
              port: 10254
              scheme: HTTP
            initialDelaySeconds: 10
            periodSeconds: 10
            successThreshold: 1
            timeoutSeconds: 10
          readinessProbe:
            failureThreshold: 3
            httpGet:
              path: /healthz
              port: 10254
              scheme: HTTP
            periodSeconds: 10
            successThreshold: 1
            timeoutSeconds: 10
      nodeSelector:
        aqsc/ingress-controller-ready: "true"
      # kubectl label nodes <节点名称> aqsc/ingress-controller-ready="true"

---
apiVersion: v1
kind: Service
metadata:
  name: ingress-nginx
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
spec:
  #type: NodePort
  ports:
  - name: metrics
    port: 10254
    targetPort: 10254
    protocol: TCP
  - name: http
    port: 80
    targetPort: 80
    protocol: TCP
  - name: https
    port: 443
    targetPort: 443
    protocol: TCP
  selector:
    app: ingress-nginx
    app.kubernetes.io/name: ingress-nginx
    app.kubernetes.io/part-of: ingress-nginx

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
55.
56.
57.
58.
59.
60.
61.
62.
63.
64.
65.
66.
67.
68.
69.
70.
71.
72.
73.
74.
75.
76.
77.
78.
79.
80.
81.
82.
83.
84.
85.
86.
87.
88.
89.
90.
91.
92.
93.
94.
95.
96.
97.
98.
99.
100.
101.
102.
103.
104.
105.
106.
107.
108.
109.
110.
111.
112.
113.
114.
115.
116.
117.
118.
119.
120.
121.
122.
123.
124.
125.
126.
127.
128.
129.
130.
131.
132.
133.
134.
135.
136.
137.
138.
139.
140.
141.
142.
143.
144.
145.
146.
147.
148.
149.
150.
151.
152.
153.
154.
155.
156.
157.
158.
159.
160.
161.
162.
163.
164.
165.
166.
167.
168.
169.
170.
171.
172.
173.
174.
175.
176.
177.
178.
179.
180.
181.
182.
183.
184.
185.
186.
187.
188.
189.
190.
191.
192.
193.
194.
195.
196.
197.
198.
199.
200.
201.
202.
203.
204.
205.
206.
207.
208.
209.
210.
211.
212.
213.
214.
215.
216.
217.
218.
219.
220.
221.
222.
223.
224.
225.
226.
227.
228.
229.
230.
231.
232.
233.
234.
235.
236.
237.
238.
239.
240.
241.
242.
243.
244.
245.
246.
247.
248.
249.
250.
251.
252.
253.
254.
255.
256.
257.
258.
259.
260.
261.
262.
263.
264.
265.
266.
267.
268.
269.
270.
271.
272.
273.
274.
275.
276.
277.
278.
279.
280.
281.
282.
283.
284.
285.
286.
287.
288.
289.
290.
291.
292.
293.
294.
295.
296.
297.
298.
299.
300.
301.
302.
303.
304.
305.
306.
307.
308.
309.
310.
311.
312.
313.
314.
315.
316.
317.
318.
319.
320.
321.
322.
323.
324.
325.
326.
327.
328.
329.
330.
331.
332.
333.
334.

过滤一下暴漏的metrics端口号上面配置文件暴露了！！！！

[root@master01 manifests]# kubectl get pods -n ingress-nginx nginx-ingress-controller-7rxlt -o yaml | egrep -A2 "port|metrics"
    prometheus.io/port: "10254"
    prometheus.io/scrape: "true"
  creationTimestamp: "2025-04-17T05:45:26Z"
--
          f:prometheus.io/port: {}
          f:prometheus.io/scrape: {}
        f:generateName: {}
--
                f:port: {}
                f:scheme: {}
              f:initialDelaySeconds: {}
--
            f:ports:
              .: {}
              k:{"containerPort":80,"protocol":"TCP"}:
--
                f:port: {}
                f:scheme: {}
              f:periodSeconds: {}
--
        port: 10254
        scheme: HTTP
      initialDelaySeconds: 10
--
    ports:
    - containerPort: 80
      hostPort: 80
--
        port: 10254
        scheme: HTTP
      periodSeconds: 10

[root@master01 manifests]# kubectl get svc -n ingress-nginx ingress-nginx
NAME            TYPE        CLUSTER-IP    EXTERNAL-IP   PORT(S)          AGE
ingress-nginx   ClusterIP   10.101.95.4   <none>        80/TCP,443/TCP   14h

#只暴露了 443和80 没有ingress的端口号

[root@master01 manifests]# kubectl edit svc -n ingress-nginx ingress-nginx

  - name: http-ingress
    port: 10254
    protocol: TCP
    targetPort: 10254


[root@master01 manifests]# kubectl get svc -n ingress-nginx
NAME            TYPE        CLUSTER-IP    EXTERNAL-IP   PORT(S)                    AGE
ingress-nginx   ClusterIP   10.101.95.4   <none>        10254/TCP,80/TCP,443/TCP   16h

加到文件里面

[root@master01 manifests]# vim /data/aqsc_k8s_yaml/ingress-nginx/ingress-nginx.yaml

          ports:
            - name: http
              containerPort: 80
            - name: https
              containerPort: 443
            - name: http-ingress
              containerPort: 10254

看下metrics指标

[root@master01 manifests]# curl 10.1.19.54:10254/metrics | tail -3
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100 11794  100 11794    0     0  5758k      0 --:--:-- --:--:-- --:--:-- 5758k
promhttp_metric_handler_requests_total{code="200"} 5
promhttp_metric_handler_requests_total{code="500"} 0
promhttp_metric_handler_requests_total{code="503"} 0
[root@master01 manifests]# curl 10.1.19.55:10254/metrics | tail -3
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100 11775  100 11775    0     0  5749k      0 --:--:-- --:--:-- --:--:-- 5749k
promhttp_metric_handler_requests_total{code="200"} 0
promhttp_metric_handler_requests_total{code="500"} 0
promhttp_metric_handler_requests_total{code="503"} 0
[root@master01 manifests]# curl 10.1.19.56:10254/metrics | tail -3
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100 11782  100 11782    0     0  5752k      0 --:--:-- --:--:-- --:--:-- 5752k
promhttp_metric_handler_requests_total{code="200"} 0
promhttp_metric_handler_requests_total{code="500"} 0
promhttp_metric_handler_requests_total{code="503"} 0

可以看到数据

创建个ServiceMonitor

ServiceMonitor 是Prometheus Operator提供的一种自定义资源(Custom Resource, CR)，用于定义Prometheus监控服务发现的目标。它允许用户指定哪些Kubernetes服务(Service)和Pod的监控数据应该被Prometheus抓取，以及抓取数据的频率、路径等配置。

---
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: ingress-nginx-monitor  #监控名称 也就是prometheus ui页面显示
  namespace: ingress-nginx
  labels:
    app: ingress-nginx
spec:
  selector:   #这个标签要匹配到 被监控监控的标签
    matchLabels:
      app: ingress-nginx
  endpoints:
  - port: metrics  #目标服务上暴露指标的端口名称。
    path: /metrics  #目标服务上暴露指标的 HTTP 路径
    interval: 30s   #监控频率 每隔30s抓取一次
      #  jobLabel: app   #指定应该使用哪个标签来将目标分组为 Prometheus 中的一个作业。在这里，使用 app 标签来标识和分组共享此标签的所有目标为同一作业。
  namespaceSelector: #指定 ServiceMonitor 应监控哪些命名空间。
    matchNames:
    - ingress-nginx  #仅选择 ingress-nginx 命名空间

root@guoguo-M5-Pro:/apps/k8s/prometheus/servicemonitor# kubectl get svc  -n kube-system nginx-ingress-lb -oyaml
.....
.....
  ports:
  - name: http
    port: 80
    protocol: TCP
    targetPort: 80
  - name: https
    port: 443
    protocol: TCP
    targetPort: 443
  - name: metrics    #这里就是给这个端口号取个名字 上面的ServiceMonitor.spce.port 引用的
    port: 10254
    protocol: TCP
    targetPort: 10254
  selector:
    app: ingress-nginx
  sessionAffinity: None
  type: ClusterIP
status:
  loadBalancer: {}

[root@master01 manifests]# kubectl delete daemonset nginx-ingress-controller -n ingress-nginx
[root@master01 manifests]# kubectl apply -f /data/aqsc_k8s_yaml/ingress-nginx/ingress-nginx.yaml

新创建的prometheus 都会遇到一个权限的报错

现在promehtues ui 页面是看不到监控项的

查看报错

root@guoguo-M5-Pro:/apps/k8s/prometheus/servicemonitor# kubectl -n monitoring logs prometheus-k8s-0 -c prometheus
......
......
level=error ts=2024-08-25T07:07:41.107Z caller=klog.go:96 component=k8s_client_runtime func=ErrorDepth msg="pkg/mod/k8s.io/client-go@v0.20.5/tools/cache/reflector.go:167: Failed to watch *v1.Endpoints: failed to list *v1.Endpoints: endpoints is forbidden: User \"system:serviceaccount:monitoring:prometheus-k8s\" cannot list resource \"endpoints\" in API group \"\" in the namespace \"ingress-nginx\""

# 当看到forbidden 就是权限问题

root@guoguo-M5-Pro:/apps/k8s/prometheus/servicemonitor# kubectl -n monitoring logs prometheus-k8s-1 -c prometheus
......
......
level=error ts=2024-08-25T07:09:33.891Z caller=klog.go:96 component=k8s_client_runtime func=ErrorDepth msg="pkg/mod/k8s.io/client-go@v0.20.5/tools/cache/reflector.go:167: Failed to watch *v1.Endpoints: failed to list *v1.Endpoints: endpoints is forbidden: User \"system:serviceaccount:monitoring:prometheus-k8s\" cannot list resource \"endpoints\" in API group \"\" in the namespace \"ingress-nginx\""

去修改prometheus 的集群角色clusterrole

root@guoguo-M5-Pro:/apps/k8s/prometheus/servicemonitor# kubectl edit clusterrole prometheus-k8s
......
......  #rules 部分改为下面  权限
rules:
- apiGroups:
  - ""
  resources:
  - nodes
  - services
  - endpoints
  - pods
  - nodes/proxy
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - ""
  resources:
  - configmaps
  - nodes/metrics
  verbs:
  - get
- nonResourceURLs:
  - /metrics
  verbs:
  - get

登录prometheus ui网站就可以看到了

yaml配置文件也修改下

改为

apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  labels:
    app.kubernetes.io/component: prometheus
    app.kubernetes.io/name: prometheus
    app.kubernetes.io/part-of: kube-prometheus
    app.kubernetes.io/version: 2.26.0
  name: prometheus-k8s
rules:
- apiGroups:
  - ""
  resources:
  - nodes
  - services
  - endpoints
  - pods
  - nodes/proxy
  verbs:
  - get
  - list
  - watch
- apiGroups:
  - ""
  resources:
  - configmaps
  - nodes/metrics
  verbs:
  - get
- nonResourceURLs:
  - /metrics
  verbs:
  - get
