三层交换机与路由期对接无法通信,求大神帮看看

交换机的配置如下：

[SW] vlan batch 10 20

[SW] interface gigabitEthernet 0/0/1

[SW-GigabitEthernet0/0/1] port link-type access

[SW-GigabitEthernet0/0/1] port default vlan 10

[SW] interface gigabitEthernet 0/0/2

[SW-GigabitEthernet0/0/2] port link-type access

[SW-GigabitEthernet0/0/2] port default vlan 20

[SW] interface Vlanif 10

[SW-vlanif10] ip address 192.168.10.254 24

[SW] interface Vlanif 20

[SW-vlanif20] ip address 192.168.20.254 24

[SW] vlan 200 #创建vlan200

[SW-vlan200] quit

[SW] interface vlanif 200

[SW-vlanif200] ip address 192.168.200.1 24

[SW-vlanif200] quit

[SW] ip route-static 0.0.0.0 0.0.0.0 192.168.200.2

配置路由器：

[Router] interface gigabitEthernet 0/0/0

[Router-GigabitEthernet0/0/0] ip address 192.168
