pom.xml 导包
<!--依赖：junit , 数据库驱动 ,连接池 , servlet , jsp , mybatis , mybatis-spring , spring -->
<dependencies>
    <!--junit-->
    <dependency>
        <groupId>junit</groupId>
        <artifactId>junit</artifactId>
        <version>4.12</version>
    </dependency>

    <!--数据库驱动-->
    <dependency>
        <groupId>mysql</groupId>
        <artifactId>mysql-connector-java</artifactId>
        <version>5.1.47</version>
    </dependency>

    <!--连接池-->
    <dependency>
        <groupId>com.mchange</groupId>
        <artifactId>c3p0</artifactId>
        <version>0.9.5.2</version>
    </dependency>

    <!--servlet  jsp-->
    <dependency>
        <groupId>javax.servlet</groupId>
        <artifactId>servlet-api</artifactId>
        <version>2.5</version>
    </dependency>
    <dependency>
        <groupId>javax.servlet.jsp</groupId>
        <artifactId>jsp-api</artifactId>
        <version>2.2</version>
    </dependency>
    <dependency>
        <groupId>javax.servlet</groupId>
        <artifactId>jstl</artifactId>
        <version>1.2</version>
    </dependency>

    <!--MyBatis-->
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis</artifactId>
        <version>3.5.2</version>
    </dependency>
    <dependency>
        <groupId>org.mybatis</groupId>
        <artifactId>mybatis-spring</artifactId>
        <version>2.0.2</version>
    </dependency>

    <!--Spring-->
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-webmvc</artifactId>
        <version>5.1.9.RELEASE</version>
    </dependency>
    <dependency>
        <groupId>org.springframework</groupId>
        <artifactId>spring-jdbc</artifactId>
        <version>5.1.9.RELEASE</version>
    </dependency>

    <dependency>
        <groupId>org.aspectj</groupId>
        <artifactId>aspectjweaver</artifactId>
        <version>1.8.13</version>
    </dependency>
    <dependency>
        <groupId>org.projectlombok</groupId>
        <artifactId>lombok</artifactId>
        <version>1.16.10</version>
    </dependency>
</dependencies>


<!--静态资源导出问题-->
<build>
    <resources>
        <resource>
            <directory>src/main/java</directory>
            <includes>
                <include>**/*.properties</include>
                <include>**/*.xml</include>
            </includes>
            <filtering>false</filtering>
        </resource>
        <resource>
            <directory>src/main/resources</directory>
            <includes>
                <include>**/*.properties</include>
                <include>**/*.xml</include>
            </includes>
            <filtering>false</filtering>
        </resource>
    </resources>
</build>

applicationContext.xml：

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans.xsd">

    <import resource="classpath:spring-dao.xml"/>
    <import resource="classpath:spring-service.xml"/>
    <import resource="classpath:spring-mvc.xml"/>
</beans>

database.properties：

jdbc.driver=com.mysql.jdbc.Driver
jdbc.jdbcUrl=jdbc:mysql://localhost:3306/ssmbuild?useSSL=true&useUnicode\=true&characterEncoding\=utf-8
jdbc.user=
jdbc.password=

mybatis-config.xml：

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-config.dtd">
<!--核心配置文件-->
<configuration>

    <settings>
        <setting name="logImpl" value="STDOUT_LOGGING"/>
    </settings>
    <!--配置数据源，交给Spring去做-->

    <typeAliases>
        <package name="com.cn.pojo"/>
    </typeAliases>

    <mappers>
        <mapper class="com.cn.dao.BookMapper"/>
    </mappers>
</configuration>

spring-dao.xml：

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:comtext="http://www.springframework.org/schema/context"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans.xsd
       http://www.springframework.org/schema/context
       https://www.springframework.org/schema/context/spring-context.xsd">
    <!--1.关联数据库配置文件-->
    <comtext:property-placeholder location="classpath:database.properties"/>

    <!--2.连接池-->
    <bean id="dataSource" class="com.mchange.v2.c3p0.ComboPooledDataSource">
        <property name="driverClass" value="${jdbc.driver}"/>
        <property name="jdbcUrl" value="${jdbc.jdbcUrl}"/>
        <property name="user" value="${jdbc.user}"/>
        <property name="password" value="${jdbc.password}"/>

        <!--c3p0连接池的私有属性-->
        <property name="maxPoolSize" value="30"/>
        <property name="minPoolSize" value="10"/>
        <!--关闭连接后不自动commit-->
        <property name="autoCommitOnClose" value="false"/>
        <!--获取连接超时时间-->
        <property name="checkoutTimeout" value="10000"/>
        <!--当获取连接失败重试次数-->
        <property name="acquireRetryAttempts" value="2"/>
    </bean>

    <!--3.sqlSessionFactory-->
    <bean id="sqlSessionFactory" class="org.mybatis.spring.SqlSessionFactoryBean">
        <property name="dataSource" ref="dataSource"/>
        <!--绑定Mybatis的配置文件-->
        <property name="configLocation" value="classpath:mybatis-config.xml"/>
    </bean>

    <!--4.配置dao接口扫描包，动态的实现Dao接口可以注入到Spring容器中-->
    <bean class="org.mybatis.spring.mapper.MapperScannerConfigurer">
        <!--注入-->
        <property name="sqlSessionFactoryBeanName" value="sqlSessionFactory"/>
        <!--要扫描的dao包-->
        <property name="basePackage" value="com.cn.dao"/>
    </bean>

</beans>

spring-mvc.xml：

<?xml version="1.0" encoding="UTF-8" ?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:context="http://www.springframework.org/schema/context"
       xmlns:mvc="http://www.springframework.org/schema/mvc"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
      http://www.springframework.org/schema/beans/spring-beans.xsd
      http://www.springframework.org/schema/context
      https://www.springframework.org/schema/context/spring-context.xsd
      http://www.springframework.org/schema/mvc
      https://www.springframework.org/schema/mvc/spring-mvc.xsd">


        <!--1.注解驱动-->
        <mvc:annotation-driven/>

        <!--2.静态资源过滤-->
        <mvc:default-servlet-handler/>

        <!--3.扫描包：controller-->
        <context:component-scan base-package="com.cn.controller"/>

        <!--4.视图解析器-->
        <bean class="org.springframework.web.servlet.view.InternalResourceViewResolver" id="internalResourceViewResolver">
            <!--前缀-->
            <property name="prefix" value="/WEB-INF/jsp/"/>
            <!--后缀-->
            <property name="suffix" value=".jsp"/>
        </bean>
</beans>

spring-service.xml：

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:context="http://www.springframework.org/schema/context"
       xmlns:aop="http://www.springframework.org/schema/aop"
       xmlns:tx="http://www.springframework.org/schema/tx"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans.xsd
       http://www.springframework.org/schema/context
       https://www.springframework.org/schema/context/spring-context.xsd
       http://www.springframework.org/schema/aop
       https://www.springframework.org/schema/aop/spring-aop.xsd
       http://www.springframework.org/schema/tx
       http://www.springframework.org/schema/tx/spring-tx.xsd">
    <!--1.扫描service下的包-->
    <context:component-scan base-package="com.cn.service"/>
    <!--2.将我们的所有业务类，注入到Spring,可以通过配置，或者注解实现-->
    <bean id="BookServiceImpl" class="com.cn.service.BookServiceImpl">
        <property name="bookMapper" ref="bookMapper"/>
    </bean>
    <!--3.声明事务配置-->
    <bean id="transactionManager" class="org.springframework.jdbc.datasource.DataSourceTransactionManager">
        <!--注入数据源-->
        <property name="dataSource" ref="dataSource"/>
    </bean>

    <!--4.aop事务支持-->

    <tx:advice id="txAdvice" transaction-manager="transactionManager">
        <tx:attributes>
            <tx:method name="*" propagation="REQUIRED"/>
        </tx:attributes>
    </tx:advice>
    <aop:config>
        <aop:pointcut id="txPointCut" expression="execution(* com.cn.dao.*.*(..))"/>
        <aop:advisor advice-ref="txAdvice" pointcut-ref="txPointCut"/>
    </aop:config>
</beans>

BookMapper:

public interface BookMapper {
    //增加一本书
    int addBook(Books books);

    //删除一本书
    int deleteBookById(@Param("bookId") int id);

    //更新一本书
    int updateBook(Books books);

    //查询一本书
    Books queryBookById(@Param("bookId") int id);

    //查询全部的书
    List<Books> queryAllBook();

    Books queryBookByName(@Param("bookName") String bookName);
}

BookService：

public interface BookService {
    //增加一本书
    int addBook(Books books);

    //删除一本书
    int deleteBookById( int id);

    //更新一本书
    int updateBook(Books books);

    //查询一本书
    Books queryBookById(int id);

    //查询全部的书
    List<Books> queryAllBook();

    Books queryBookByName(String bookName);
}

BookServiceImpl：

@Service
public class BookServiceImpl implements BookService {
    @Autowired
    private BookMapper bookMapper;

    public void setBookMapper(BookMapper bookMapper) {
        this.bookMapper = bookMapper;
    }

    public int addBook(Books books) {
        return bookMapper.addBook(books);
    }

    public int deleteBookById(int id) {
        return bookMapper.deleteBookById(id);
    }

    public int updateBook(Books books) {
        return bookMapper.updateBook(books);
    }

    public Books queryBookById(int id) {
        return bookMapper.queryBookById(id);
    }

    public List<Books> queryAllBook() {
        return bookMapper.queryAllBook();
    }

    public Books queryBookByName(String bookName) {
        return bookMapper.queryBookByName(bookName);
    }
}

BookController：

@Controller
@RequestMapping("/book")
public class BookController {
    @Autowired
    @Qualifier("BookServiceImpl")
    private BookService bookService;

    //重新全部的书籍，并返回到一个书籍展示页面
    @RequestMapping("/allBook")
    public String list(Model model){
        List<Books> list = bookService.queryAllBook();
        model.addAttribute("list",list);
        return "allBook";
    }


    //跳转到增加书籍页面
    @RequestMapping("/toAddBook")
    public String toAddPapre(){

        return "addBook";
    }
    //添加书籍的请求
    @RequestMapping("/addBook")
    public String addBook(Books books){
        bookService.addBook(books);
        return "redirect:/book/allBook";
    }

    //跳到修改页面
    @RequestMapping("/toUpdate")
    public String toUpdatePaper(int id,Model model){
        Books books = bookService.queryBookById(id);
        model.addAttribute("QBooks",books);
        return "updateBook";
    }

    //修改书籍
    @RequestMapping("/updateBook")
    public String updateBook(Books books){
        bookService.updateBook(books);
        return "redirect:/book/allBook";
    }


    //删除书籍
    @RequestMapping("/deleteBook/{bookID}")
    public String deleteBook(@PathVariable("bookID") int id){
        bookService.deleteBookById(id);
        return "redirect:/book/allBook";
    }

    //查询书籍
    @RequestMapping("/queryBook")
    public String queryBook(String queryBookName,Model model){
        Books books = bookService.queryBookByName(queryBookName);

        List<Books> list = new ArrayList<Books>();
        list.add(books);

        if (books==null){
            list=bookService.queryAllBook();
            model.addAttribute("error","未查到");
        }

        model.addAttribute("list",list);
        return "allBook";
    }
}

BookMapper.xml：

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<!--核心配置文件-->
<mapper namespace="com.cn.dao.BookMapper">

    <insert id="addBook" parameterType="Books">
        insert into ssmbuild.books(bookName, bookCounts, detail)
        values (#{bookName},#{bookCounts},#{detail});
    </insert>

    <delete id="deleteBookById" parameterType="int">
        delete from  ssmbuild.books where bookID = #{bookId}
    </delete>

    <update id="updateBook" parameterType="Books">
        update ssmbuild.books
        set bookName=#{bookName},bookCounts=#{bookCounts},detail=#{detail}
        where bookID=#{bookID};
    </update>

    <select id="queryBookById" resultType="Books">
        select * from ssmbuild.books
        where bookID = #{bookId}
    </select>

    <select id="queryAllBook" resultType="Books">
        select * from ssmbuild.books
    </select>

    <select id="queryBookByName" resultType="Books">
        select * from ssmbuild.books where bookName= #{bookName}
    </select>
</mapper>

web.xml:

<?xml version="1.0" encoding="UTF-8"?>
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_4_0.xsd"
         version="4.0">

<!--DispatcherServlet-->
<servlet>
    <servlet-name>springmvc</servlet-name>
    <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
    <init-param>
        <param-name>contextConfigLocation</param-name>
        <param-value>classpath:applicationContext.xml</param-value>
    </init-param>
    <load-on-startup>1</load-on-startup>
</servlet>
<servlet-mapping>
    <servlet-name>springmvc</servlet-name>
    <url-pattern>/</url-pattern>
</servlet-mapping>

<!--乱码过滤-->
<filter>
    <filter-name>encodingFilter</filter-name>
    <filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
    <init-param>
        <param-name>encoding</param-name>
        <param-value>utf-8</param-value>
    </init-param>
</filter>
<filter-mapping>
    <filter-name>encodingFilter</filter-name>
    <url-pattern>/*</url-pattern>
</filter-mapping>

<!--Session-->
<session-config>
    <session-timeout>15</session-timeout>
</session-config>
</web-app>

index.jsp:

<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
  <head>
    <title>$Title$</title>
    <style>
      a{
        text-decoration: none;
        color: black;
        font-size: 18px;
      }
      h3{
        width: 180px;
        height: 38px;
        margin: 100px auto;
        text-align: center;
        line-height: 38px;
        background: deepskyblue;
        border-radius: 5px;
      }
    </style>
  </head>
  <body>
  <h2>
    <a href="${pageContext.request.contextPath}/book/allBook">进入书籍页面</a>
  </h2>
  </body>
</html>

addBook.jsp:

<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>Title</title>
    <link href="https://cdn.staticfile.org/twitter-bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet">
</head>
<body>

<div class="container">

    <div class="row clearfix">
        <div class="col-md-12 colum">
            <div class="page-header">
                <h1>
                    <small>新增书籍</small>
                </h1>
            </div>
        </div>

        <form action="${pageContext.request.contextPath}/book/addBook" method="post">
            <div class="form-group">
                <label>书籍名称：</label>
                <input type="text" name="bookName" class="form-control" required>
            </div>
            <div class="form-group">
                <label>书籍数量：</label>
                <input type="text" name="bookCounts" class="form-control" required>
            </div>
            <div class="form-group">
                <label>书籍描述：</label>
                <input type="text" name="detail" class="form-control" required>
            </div>
            <div class="form-group">
                <input type="submit" class="form-control" value="添加">
            </div>

        </form>

    </div>
</div>

</body>
</html>

allBook.jsp；

<%@ taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %>
<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>书籍展示</title>
    <link href="https://cdn.staticfile.org/twitter-bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet">
</head>
<body>

<div class="container">

    <div class="row clearfix">
        <div class="col-md-12 colum">
            <div class="page-header">
                <h1>
                    <small>书籍列表————显示所有书籍</small>
                </h1>
            </div>

            <div class="row">
                <div class="col-md-4 colum">

                    <a class="btn btn-primary" href="${pageContext.request.contextPath}/book/toAddBook">新增书籍</a>
                    <a class="btn btn-primary" href="${pageContext.request.contextPath}/book/allBook">显示全部书籍</a>
                </div>
                <div class="col-md-8 colum">
                    <form class="form-inline" action="${pageContext.request.contextPath}/book/queryBook" method="post" style="float:right">
                        <span style="color: red ;font-weight: bold">${error}</span>
                        <input type="text" name="queryBookName" class="form-control" placeholder="请输入要重新的书籍名称">
                        <input type="submit" value="查询" class="btn btn-primary">
                    </form>
                </div>

            </div>
        </div>


        <div class="row clearfix">
            <div class="col-md-12 colum">
                <table class="table table-hover table-striped">
                    <thead>
                        <tr>
                            <th>书籍标号</th>
                            <th>书籍名称</th>
                            <th>书籍数量</th>
                            <th>书籍详情</th>
                            <th>操作</th>
                        </tr>
                    </thead>

                    <tbody>
                        <c:forEach var="book" items="${list}">
                            <tr>
                                <td>${book.bookID}</td>
                                <td>${book.bookName}</td>
                                <td>${book.bookCounts}</td>
                                <td>${book.detail}</td>
                                <td>
                                    <a href="${pageContext.request.contextPath}/book/toUpdate?id=${book.bookID}">修改</a>
                                    &nbsp; | &nbsp;
                                    <a href="${pageContext.request.contextPath}/book/deleteBook/${book.bookID}">删除</a>
                                </td>
                            </tr>
                        </c:forEach>
                    </tbody>
                </table>
            </div>
        </div>
    </div>
</div>

</body>
</html>

updateBook.jsp：

<%@ page contentType="text/html;charset=UTF-8" language="java" %>
<html>
<head>
    <title>修改书籍</title>
    <link href="https://cdn.staticfile.org/twitter-bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet">
</head>
<body>

<div class="container">

    <div class="row clearfix">
        <div class="col-md-12 colum">
            <div class="page-header">
                <h1>
                    <small>修改书籍</small>
                </h1>
            </div>
        </div>

        <form action="${pageContext.request.contextPath}/book/updateBook" method="post">

            <input type="hidden" name="bookID" value="${QBooks.bookID}">
            <div class="form-group">
                <label>书籍名称：</label>
                <input type="text" name="bookName" class="form-control" value="${QBooks.bookName}" required>
            </div>
            <div class="form-group">
                <label>书籍数量：</label>
                <input type="text" name="bookCounts" class="form-control" value="${QBooks.bookCounts}" required>
            </div>
            <div class="form-group">
                <label>书籍描述：</label>
                <input type="text" name="detail" class="form-control" value="${QBooks.detail}" required>
            </div>
            <div class="form-group">
                <input type="submit" class="form-control" value="修改">
            </div>

        </form>

    </div>
</div>

</body>
</html>

mytest:

public class MyTest {
    @Test
    public void test(){
        ApplicationContext context = new ClassPathXmlApplicationContext("applicationContext.xml");
        BookService bookServiceImpl = (BookService) context.getBean("BookServiceImpl");
        for (Books books :bookServiceImpl.queryAllBook()){
            System.out.println(books);
        }
    }
}
