感知SQL运行时的状态
1. 说在前面的话
在MySQL里，一条SQL运行时产生多少磁盘I/O，占用多少内存，是否有创建临时表，这些指标如果都能观测到，有助于更快发现SQL瓶颈，扑灭潜在隐患。
从MySQL 5.7版本开始，performance_schema就默认启用了，并且还增加了sys schema，到了8.0版本又进一步得到增强提升，在SQL运行时就能观察到很多有用的信息，实现一定程度的可观测性。
下面举例说明如何进行观测，以及主要观测哪些指标。
2. 安装employees测试库
安装MySQL官方提供的employees测试数据库，戳此链接(https://dev.mysql.com/doc/index-other.html)下载，解压缩后开始安装：
$ mysql -f < employees.sql;
INFO
CREATING DATABASE STRUCTURE
INFO
storage engine: InnoDB
INFO
LOADING departments
INFO
LOADING employees
INFO
LOADING dept_emp
INFO
LOADING dept_manager
INFO
LOADING titles
INFO
LOADING salaries
data_load_time_diff
00:00:37MySQL还提供了相应的使用文档：https://dev.mysql.com/doc/employee/en/
本次测试采用GreatSQL 8.0.32-24版本，且运行在MGR环境中：
greatsql> \s
...
Server version: 8.0.32-24 GreatSQL, Release 24, Revision 3714067bc8c
...
greatsql> select MEMBER_ID, MEMBER_ROLE, MEMBER_VERSION from performance_schema.replication_group_members;
+--------------------------------------+-------------+----------------+
| MEMBER_ID | MEMBER_ROLE | MEMBER_VERSION |
+--------------------------------------+-------------+----------------+
| 2adec6d2-febb-11ed-baca-d08e7908bcb1 | SECONDARY | 8.0.32 |
| 2f68fee2-febb-11ed-b51e-d08e7908bcb1 | ARBITRATOR | 8.0.32 |
| 5e34a5e2-feb6-11ed-b288-d08e7908bcb1 | PRIMARY | 8.0.32 |
+--------------------------------------+-------------+----------------+3. 观测SQL运行状态
查看当前连接/会话的连接ID、内部线程ID：
greatsql> select processlist_id, thread_id from performance_schema.threads where processlist_id = connection_id();
+----------------+-----------+
| processlist_id | thread_id |
+----------------+-----------+
| 110 | 207 |
+----------------+-----------+查询得到当前的连接ID=110，内部线程ID=207。
P.S，由于本文整理过程不是连续的，所以下面看到的 thread_id 值可能会有好几个，每次都不同。
3.1 观测SQL运行时的内存消耗
执行下面的SQL，查询所有员工的薪资总额，按员工号分组，并按薪资总额倒序，取前10条记录：
greatsql> explain select emp_no, sum(salary) as total_salary from salaries group by emp_no order by total_salary desc limit 10\G
*************************** 1. row ***************************
id: 1
select_type: SIMPLE
table: salaries
partitions: NULL
type: index
possible_keys: PRIMARY
key: PRIMARY
key_len: 7
ref: NULL
rows: 2838426
filtered: 100.00
Extra: Using temporary; Using filesort看到需要全索引扫描（其实也等同于全表扫描，因为是基于PRIMARY索引），并且还需要生成临时表，以及额外的filesort。
在正式运行该SQL之前，在另外的窗口中新建一个连接会话，执行下面的SQL先观察该连接/会话当前的内存分配情况：
greatsql> select * from sys.x$memory_by_thread_by_current_bytes where thread_id = 207\G
*************************** 1. row ***************************
thread_id: 207
user: root@localhost
current_count_used: 9
current_allocated: 26266
current_avg_alloc: 2918.4444
current_max_alloc: 16464
total_allocated: 30311等到该SQL执行完了，再一次查询内存分配情况：
greatsql> select * from sys.x$memory_by_thread_by_current_bytes where thread_id = 207\G
*************************** 1. row ***************************
thread_id: 207
user: root@localhost
current_count_used: 13
current_allocated: 24430
current_avg_alloc: 1879.2308
current_max_alloc: 16456
total_allocated: 95719我们注意到几个数据的变化情况，用下面表格来展示：
| 指标 | 运行前 | 运行后 |
|---|---|---|
| total_allocated | 30311 | 95719 |
也就是说，SQL运行时，需要分配的内存是：95719 - 30311 = 65408 字节。
3.2 观测SQL运行时的其他开销
通过观察 performance_schema.status_by_thread 表，可以知道相应连接/会话中SQL运行的一些状态指标。在SQL运行结束后，执行下面的SQL命令即可查看：
greatsql> select * from performance_schema.status_by_thread where thread_id = 207;
...
| 207 | Created_tmp_disk_tables | 0 |
| 207 | Created_tmp_tables | 0 |
...
| 207 | Handler_read_first | 1 |
| 207 | Handler_read_key | 1 |
| 207 | Handler_read_last | 0 |
| 207 | Handler_read_next | 2844047 |
| 207 | Handler_read_prev | 0 |
| 207 | Handler_read_rnd | 0 |
| 207 | Handler_read_rnd_next | 0 |
| 207 | Handler_rollback | 0 |
| 207 | Handler_savepoint | 0 |
| 207 | Handler_savepoint_rollback | 0 |
| 207 | Handler_update | 0 |
| 207 | Handler_write | 0 |
| 207 | Last_query_cost | 286802.914893 |
| 207 | Last_query_partial_plans | 1 |
...
| 207 | Select_full_join | 0 |
| 207 | Select_full_range_join | 0 |
| 207 | Select_range | 0 |
| 207 | Select_range_check | 0 |
| 207 | Select_scan | 1 |
| 207 | Slow_launch_threads | 0 |
| 207 | Slow_queries | 1 |
| 207 | Sort_merge_passes | 0 |
| 207 | Sort_range | 0 |
| 207 | Sort_rows | 1 |
| 207 | Sort_scan | 1 |
...上面我们只罗列了部分比较重要的状态指标。从这个结果也可以佐证slow query log中的结果，确实没创建临时表。
作为参照，查看这条SQL对应的slow query log记录：
# Query_time: 0.585593 Lock_time: 0.000002 Rows_sent: 10 Rows_examined: 2844057 Thread_id: 110 Errno: 0 Killed: 0 Bytes_received: 115 Bytes_sent: 313 Read_first: 1 Read_last: 0 Read_key: 1 Read_next: 2844047 Read_prev: 0 Read_rnd: 0 Read_rnd_next: 0 Sort_merge_passes: 0 Sort_range_count: 0 Sort_rows: 10 Sort_scan_count: 1 Created_tmp_disk_tables: 0 Created_tmp_tables: 0 Start: 2023-07-06T10:06:01.438376+08:00 End: 2023-07-06T10:06:02.023969+08:00 Schema: employees Rows_affected: 0
# Tmp_tables: 0 Tmp_disk_tables: 0 Tmp_table_sizes: 0
# InnoDB_trx_id: 0
# Full_scan: Yes Full_join: No Tmp_table: No Tmp_table_on_disk: No
# Filesort: Yes Filesort_on_disk: No Merge_passes: 0
# InnoDB_IO_r_ops: 0 InnoDB_IO_r_bytes: 0 InnoDB_IO_r_wait: 0.000000
# InnoDB_rec_lock_wait: 0.000000 InnoDB_queue_wait: 0.000000
# InnoDB_pages_distinct: 4281
use employees;
SET timestamp=1688609161;
select emp_no, sum(salary) as total_salary from salaries group by emp_no order by total_salary desc limit 10;可以看到，Created_tmp_disk_tables, Created_tmp_tables, Handler_read_next, Select_full_join, Select_scan, Sort_rows, Sort_scan, 等几个指标的数值是一样的。
还可以查看该SQL运行时的I/O latency情况，SQL运行前后两次查询对比：
greatsql> select * from sys.io_by_thread_by_latency where thread_id = 207;
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+
| user | total | total_latency | min_latency | avg_latency | max_latency | thread_id | processlist_id |
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+
| root@localhost | 7 | 75.39 us | 5.84 us | 10.77 us | 22.12 us | 207 | 110 |
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+
...
greatsql> select * from sys.io_by_thread_by_latency where thread_id = 207;
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+
| user | total | total_latency | min_latency | avg_latency | max_latency | thread_id | processlist_id |
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+
| root@localhost | 8 | 85.29 us | 5.84 us | 10.66 us | 22.12 us | 207 | 110 |
+----------------+-------+---------------+-------------+-------------+-------------+-----------+----------------+可以看到这个SQL运行时的I/O latency是：85.29 - 75.39 = 9.9us。
3.3 观测SQL运行进度
我们知道，运行完一条SQL后，可以利用PROFLING功能查看它各个阶段的耗时，但是在运行时如果也想查看各阶段耗时该怎么办呢？
从MySQL 5.7版本开始，可以通过 performance_schema.events_stages_% 相关表查看SQL运行过程以及各阶段耗时，需要先修改相关设置：
# 确认是否对所有主机&用户都启用
greatsql> SELECT * FROM performance_schema.setup_actors;
+------+------+------+---------+---------+
| HOST | USER | ROLE | ENABLED | HISTORY |
+------+------+------+---------+---------+
| % | % | % | NO | NO |
+------+------+------+---------+---------+
# 修改成对所有主机&用户都启用
greatsql> UPDATE performance_schema.setup_actors
SET ENABLED = 'YES', HISTORY = 'YES'
WHERE HOST = '%' AND USER = '%';
# 修改 setup_instruments & setup_consumers 设置
greatsql> UPDATE performance_schema.setup_consumers
SET ENABLED = 'YES'
WHERE NAME LIKE '%events_statements_%';
greatsql> UPDATE performance_schema.setup_consumers
SET ENABLED = 'YES'
WHERE NAME LIKE '%events_stages_%'; 这就实时可以观测SQL运行过程中的状态了。
在SQL运行过程中，从另外的窗口查看该SQL对应的 EVENT_ID：
greatsql> SELECT EVENT_ID, TRUNCATE(TIMER_WAIT/1000000000000,6) as Duration, SQL_TEXT FROM performance_schema.events_statements_history WHERE thread_id = 85 order by event_id desc limit 5;
+----------+----------+-------------------------------------------------------------------------------------------------------------------------------+
| EVENT_ID | Duration | SQL_TEXT |
+----------+----------+-------------------------------------------------------------------------------------------------------------------------------+
| 149845 | 0.6420 | select emp_no, sum(salary) as total_salary, sleep(0.000001) from salaries group by emp_no order by total_salary desc limit 10 |
| 149803 | 0.6316 | select emp_no, sum(salary) as total_salary, sleep(0.000001) from salaries group by emp_no order by total_salary desc limit 10 |
| 149782 | 0.6245 | select emp_no, sum(salary) as total_salary, sleep(0.000001) from salaries group by emp_no order by total_salary desc limit 10 |
| 149761 | 0.6361 | select emp_no, sum(salary) as total_salary, sleep(0.000001) from salaries group by emp_no order by total_salary desc limit 10 |
| 149740 | 0.6245 | select emp_no, sum(salary) as total_salary, sleep(0.000001) from salaries group by emp_no order by total_salary desc limit 10 |
+----------+----------+-------------------------------------------------------------------------------------------------------------------------------+
# 再根据 EVENT_ID 值去查询 events_stages_history_long
greatsql> SELECT thread_id ,event_Id, event_name AS Stage, TRUNCATE(TIMER_WAIT/1000000000000,6) AS Duration FROM performance_schema.events_stages_history_long WHERE NESTING_EVENT_ID = 149845 order by event_id;
+-----------+----------+------------------------------------------------+----------+
| thread_id | event_Id | Stage | Duration |
+-----------+----------+------------------------------------------------+----------+
| 85 | 149846 | stage/sql/starting | 0.0000 |
| 85 | 149847 | stage/sql/Executing hook on transaction begin. | 0.0000 |
| 85 | 149848 | stage/sql/starting | 0.0000 |
| 85 | 149849 | stage/sql/checking permissions | 0.0000 |
| 85 | 149850 | stage/sql/Opening tables | 0.0000 |
| 85 | 149851 | stage/sql/init | 0.0000 |
| 85 | 149852 | stage/sql/System lock | 0.0000 |
| 85 | 149854 | stage/sql/optimizing | 0.0000 |
| 85 | 149855 | stage/sql/statistics | 0.0000 |
| 85 | 149856 | stage/sql/preparing | 0.0000 |
| 85 | 149857 | stage/sql/Creating tmp table | 0.0000 |
| 85 | 149858 | stage/sql/executing | 0.6257 |
| 85 | 149859 | stage/sql/end | 0.0000 |
| 85 | 149860 | stage/sql/query end | 0.0000 |
| 85 | 149861 | stage/sql/waiting for handler commit | 0.0000 |
| 85 | 149862 | stage/sql/closing tables | 0.0000 |
| 85 | 149863 | stage/sql/freeing items | 0.0000 |
| 85 | 149864 | stage/sql/logging slow query | 0.0000 |
| 85 | 149865 | stage/sql/cleaning up | 0.0000 |
+-----------+----------+------------------------------------------------+----------+上面就是这条SQL的运行进度展示，以及各个阶段的耗时，和PROFILING的输出一样，当我们了解一条SQL运行所需要经历的各个阶段时，从上面的输出结果中也就能估算出该SQL大概还要多久能跑完，决定是否要提前kill它。
如果想要观察DDL SQL的运行进度，可以参考这篇文章：不用MariaDB/Percona也能查看DDL的进度。
更多的观测指标、维度还有待继续挖掘，以后有机会再写。
另外，也可以利用MySQL Workbench工具，或MySQL Enterprise Monitor，都已集成了很多可观测性指标，相当不错的体验。
延伸阅读
- Query Profiling Using Performance Schema, https://dev.mysql.com/doc/refman/8.0/en/performance-schema-query-profiling.html
- 不用MariaDB/Percona也能查看DDL的进度，https://mp.weixin.qq.com/s?__biz=MjM5NzAzMTY4NQ==&mid=2653931466&idx=1&sn=8c14c7a6449205b61990a567a1be315e&scene=21#wechat_redirect
- 事件记录 | performance_schema全方位介绍，http://mp.weixin.qq.com/s?__biz=MjM5NzAzMTY4NQ==&mid=2653935075&idx=3&sn=85be3a5bbe6be8bacd2a88e22ab95b5c&chksm=bd3b4f898a4cc69fb303f977912f4ee4a399ab96b72b8d994e262b1095edad4c7e2e6f45dc9b&scene=21#wechat_redirect
- 内存分配统计视图 | 全方位认识 sys 系统库，http://mp.weixin.qq.com/s?__biz=MjM5NzAzMTY4NQ==&mid=2653935156&idx=6&sn=3061ca49bdefd61eca1fe9b3c52097a1&chksm=bd3b4c5e8a4cc5480e6c27dc42a68837a113abea4279b4ae492078f263cb65421c99dc39d978&scene=21#wechat_redirect
Enjoy GreatSQL :)
