.word __rel_dyn_start - _start

_rel_dyn_end_ofs:
.word __rel_dyn_end - _start
_dynsym_start_ofs:
.word __dynsym_start - _start
ENDPROC(relocate_code)

#endif

ENTRY(c_runtime_cpu_setup)
/*

If I-cache is enabled invalidate it
/
#ifndef CONFIG_SYS_ICACHE_OFF
mcr p15, 0, r0, c7, c5, 0 @ invalidate icache
mcr p15, 0, r0, c7, c10, 4 @ DSB
mcr p15, 0, r0, c7, c5, 4 @ ISB
#endif
/
Move vector table
/
#if !defined(CONFIG_TEGRA20)
/ Set vector address in CP15 VBAR register /
ldr r0, =_start
add r0, r0, r9
mcr p15, 0, r0, c12, c0, 0 @Set VBAR
#endif / !Tegra20 */

bx lr

ENDPROC(c_runtime_cpu_setup)

/*************************************************************************
*

void save_boot_params(u32 r0, u32 r1, u32 r2, u32 r3)
attribute((weak));
Stack pointer is not yet initialized at this moment
Don’t save anything to stack even if compiled with -O0

*************************************************************************/
ENTRY(save_boot_params)
bx lr @ back to my caller
ENDPROC(save_boot_params)
.weak save_boot_params

/*************************************************************************
*

cpu_init_cp15
Setup CP15 registers (cache, MMU, TLBs). The I-cache is turned on unless
CONFIG_SYS_ICACHE_OFF is defined.

*************************************************************************/
ENTRY(cpu_init_cp15)

/*
* Invalidate L1 I/D
*/
mov r0, #0 @ set up for MCR
mcr p15, 0, r0, c8, c7, 0 @ invalidate TLBs
mcr p15, 0, r0, c7, c5, 0 @ invalidate icache

/*
* disable MMU stuff and caches
*/
mrc p15, 0, r0, c1, c0, 0
bic r0, r0, #0x00002000 @ clear bits 13 (–V-)
bic r0, r0, #0x00000007 @ clear bits 2:0 (-CAM)
orr r0, r0, #0x00000002 @ set bit 1 (–A-) Align
orr r0, r0, #0x00000800 @ set bit 12 (Z—) BTB
mcr p15, 0, r0, c1, c0, 0

mov	pc, lr			@ back to my caller

ENDPROC(cpu_init_cp15)

#ifndef CONFIG_SKIP_LOWLEVEL_INIT
/*************************************************************************
*

CPU_init_critical registers
setup important registers
setup memory timing

************************************************************************/
ENTRY(cpu_init_crit)
/
* Jump to board specific initialization…
* The Mask ROM will have already initialized
* basic memory. Go here to bump up clock rate and handle
* wake up conditions.
*/
b lowlevel_init @ go setup pll,mux,memory
ENDPROC(cpu_init_crit)
#endif

/*************************************************************************
*

zsy210_iic_pm_open

************************************************************************/
ENTRY(zsy210_iic_pm_open)
/电源管理，保持供电/
#ifdef CONFIG_ZSY210_IIC_PM_CHIP
/ PS_HOLD(GPJ2_5) 设置为高点平 */
ldr r0, =ELFIN_GPIO_BASE
ldr r1, =0x00100000
str r1, [r0, #GPJ2CON_OFFSET]

ldr		r1, =0x0400
str		r1, [r0, #GPJ2PUD_OFFSET]

ldr		r1, =0x20
str		r1, [r0, #GPJ2DAT_OFFSET]

#endif /* CONFIG_ZSY210_IIC_PM_CHIP */
mov pc, lr @ back to my caller
ENDPROC(zsy210_iic_pm_open)

#if defined(CONFIG_ENABLE_MMU)
_mmu_table_base:
.word mmu_table
#endif

we assume that cache operation is done before. (eg. cleanup_before_linux())
actually, we don’t need to do anything about cache if not use d-cache in U-Boot
So, in this function we clean only MMU. by scsuh
void theLastJump(void *kernel, int arch_num, uint boot_params);
/
#if defined(CONFIG_ENABLE_MMU)
.globl theLastJump
theLastJump:
mov r9, r0
ldr r3, =0xfff00000
ldr r4, _TEXT_PHY_BASE
adr r5, phy_last_jump
bic r5, r5, r3
orr r5, r5, r4
mov pc, r5
phy_last_jump:
/
- disable MMU stuff
  /
  mrc p15, 0, r0, c1, c0, 0
  bic r0, r0, #0x00002300 / clear bits 13, 9:8 (–V- --RS) /
  bic r0, r0, #0x00000087 / clear bits 7, 2:0 (B— -CAM) /
  orr r0, r0, #0x00000002 / set bit 2 (A) Align /
  orr r0, r0, #0x00001000 / set bit 12 (I) I-Cache */
  mcr p15, 0, r0, c1, c0, 0
mcr p15, 0, r0, c8, c7, 0 /* flush v4 TLB */

mov r0, #0
mov pc, r9
#endif

#ifndef CONFIG_SPL_BUILD
/*

Interrupt handling

*/
@
@ IRQ stack frame.
@
#define S_FRAME_SIZE 72

#define S_OLD_R0 68
#define S_PSR 64
#define S_PC 60
#define S_LR 56
#define S_SP 52

#define S_IP 48
#define S_FP 44
#define S_R10 40
#define S_R9 36
#define S_R8 32
#define S_R7 28
#define S_R6 24
#define S_R5 20
#define S_R4 16
#define S_R3 12
#define S_R2 8
#define S_R1 4
#define S_R0 0

#define MODE_SVC 0x13
#define I_BIT 0x80

use bad_save_user_regs for abort/prefetch/undef/swi …
use irq_save_user_regs / irq_restore_user_regs for IRQ/FIQ handling
*/

.macro bad_save_user_regs
sub sp, sp, #S_FRAME_SIZE @ carve out a frame on current
@ user stack
stmia sp, {r0 - r12} @ Save user registers (now in
@ svc mode) r0-r12
ldr r2, IRQ_STACK_START_IN @ set base 2 words into abort
@ stack
ldmia r2, {r2 - r3} @ get values for “aborted” pc
@ and cpsr (into parm regs)
add r0, sp, #S_FRAME_SIZE @ grab pointer to old stack

add r5, sp, #S_SP
mov r1, lr
stmia r5, {r0 - r3} @ save sp_SVC, lr_SVC, pc, cpsr
mov r0, sp @ save current stack into r0
@ (param register)
.endm

.macro irq_save_user_regs
sub sp, sp, #S_FRAME_SIZE
stmia sp, {r0 - r12} @ Calling r0-r12
add r8, sp, #S_PC @ !! R8 NEEDS to be saved !!
@ a reserved stack spot would
@ be good.
stmdb r8, {sp, lr}^ @ Calling SP, LR
str lr, [r8, #0] @ Save calling PC
mrs r6, spsr
str r6, [r8, #4] @ Save CPSR
str r0, [r8, #8] @ Save OLD_R0
mov r0, sp
.endm

.macro irq_restore_user_regs
ldmia sp, {r0 - lr}^ @ Calling r0 - lr
mov r0, r0
ldr lr, [sp, #S_PC] @ Get PC
add sp, sp, #S_FRAME_SIZE
subs pc, lr, #4 @ return & move spsr_svc into
@ cpsr
.endm

.macro get_bad_stack
ldr r13, IRQ_STACK_START_IN @ setup our mode stack (enter
@ in banked mode)

str lr, [r13] @ save caller lr in position 0
@ of saved stack
mrs lr, spsr @ get the spsr
str lr, [r13, #4] @ save spsr in position 1 of
@ saved stack

mov r13, #MODE_SVC @ prepare SVC-Mode
@ msr spsr_c, r13
msr spsr, r13 @ switch modes, make sure
@ moves will execute
mov lr, pc @ capture return pc
movs pc, lr @ jump to next instruction &
@ switch modes.
.endm

.macro get_bad_stack_swi
sub r13, r13, #4 @ space on current stack for
@ scratch reg.
str r0, [r13] @ save R0’s value.
ldr r0, IRQ_STACK_START_IN @ get data regions start
@ spots for abort stack
str lr, [r0] @ save caller lr in position 0
@ of saved stack
mrs r0, spsr @ get the spsr
str lr, [r0, #4] @ save spsr in position 1 of
@ saved stack
ldr r0, [r13] @ restore r0
add r13, r13, #4 @ pop stack entry
.endm

.macro get_irq_stack @ setup IRQ stack
ldr sp, IRQ_STACK_START
.endm

.macro get_fiq_stack @ setup FIQ stack
ldr sp, FIQ_STACK_START
.endm

exception handlers
*/
.align 5
undefined_instruction:
get_bad_stack
bad_save_user_regs
bl do_undefined_instruction

.align 5
software_interrupt:
get_bad_stack_swi
bad_save_user_regs
bl do_software_interrupt

.align 5
prefetch_abort:
get_bad_stack
bad_save_user_regs
bl do_prefetch_abort

.align 5
data_abort:
get_bad_stack
bad_save_user_regs
bl do_data_abort

.align 5
not_used:
get_bad_stack
bad_save_user_regs
bl do_not_used

#ifdef CONFIG_USE_IRQ

.align	5

irq:
get_irq_stack
irq_save_user_regs
bl do_irq
irq_restore_user_regs

.align	5

fiq:
get_fiq_stack
/* someone ought to write a more effective fiq_save_user_regs */
irq_save_user_regs
bl do_fiq
irq_restore_user_regs

#else

.align	5

irq:
get_bad_stack
bad_save_user_regs
bl do_irq

.align	5

fiq:
get_bad_stack
bad_save_user_regs
bl do_fiq

#endif /* CONFIG_USE_IRQ /
#endif / CONFIG_SPL_BUILD */























lowlevel\_init.S的完整代码:

Copyright © 2009 Samsung Electronics
Kyungmin Park kyungmin.park@samsung.com
Minkyu Kang mk7.kang@samsung.com
See file CREDITS for list of people who contributed to this
project.
This program is free software; you can redistribute it and/or
modify it under the terms of the GNU General Public License as
published by the Free Software Foundation; either version 2 of
the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program; if not, write to the Free Software
Foundation, Inc., 59 Temple Place, Suite 330, Boston,
MA 02111-1307 USA
*/

#include <config.h>
#include <version.h>
#include <asm/arch/cpu.h>
#include <asm/arch/power.h>
#include <s5pv210.h>
#include “zsy210_val.h”
/*

Register usages:
r5 has zero always
*/

_TEXT_BASE:
.word CONFIG_SYS_TEXT_BASE

.globl lowlevel_init

lowlevel_init:
mov r9, lr

/* check reset status  */
ldr	r0, =(ELFIN_CLOCK_POWER_BASE+RST_STAT_OFFSET)
ldr	r1, [r0]
bic	r1, r1, #0xfff6ffff
cmp	r1, #0x10000
beq	wakeup_reset_pre
cmp	r1, #0x80000
beq	wakeup_reset_from_didle

/* IO Retention release */
ldr	r0, =(ELFIN_CLOCK_POWER_BASE + OTHERS_OFFSET)
ldr	r1, [r0]
ldr	r2, =IO_RET_REL
orr	r1, r1, r2
str	r1, [r0]

/* Disable Watchdog */
ldr	r0, =ELFIN_WATCHDOG_BASE	/* 0xE2700000 */
mov	r1, #0
str	r1, [r0]
/* SRAM(2MB) init for SMDKC110 */
/* GPJ1 SROM_ADDR_16to21 */
ldr	r0, =ELFIN_GPIO_BASE

ldr	r1, [r0, #GPJ1CON_OFFSET]
bic	r1, r1, #0xFFFFFF
ldr	r2, =0x444444
orr	r1, r1, r2
str	r1, [r0, #GPJ1CON_OFFSET]

ldr	r1, [r0, #GPJ1PUD_OFFSET]
ldr	r2, =0x3ff
bic	r1, r1, r2
str	r1, [r0, #GPJ1PUD_OFFSET]

/* GPJ4 SROM_ADDR_16to21 */
ldr	r1, [r0, #GPJ4CON_OFFSET]
bic	r1, r1, #(0xf<<16)
ldr	r2, =(0x4<<16)
orr	r1, r1, r2
str	r1, [r0, #GPJ4CON_OFFSET]

ldr	r1, [r0, #GPJ4PUD_OFFSET]
ldr	r2, =(0x3<<8)
bic	r1, r1, r2
str	r1, [r0, #GPJ4PUD_OFFSET]

/* CS0 - 16bit sram, enable nBE, Byte base address */
ldr	r0, =ELFIN_SROM_BASE	/* 0xE8000000 */
mov	r1, #0x1
str	r1, [r0]

/* PS_HOLD pin(GPH0_0) set to high */
ldr	r0, =(ELFIN_CLOCK_POWER_BASE + PS_HOLD_CONTROL_OFFSET)
ldr	r1, [r0]
orr	r1, r1, #0x300
orr	r1, r1, #0x1
str	r1, [r0]

/* when we already run in ram, we don't need to relocate U-Boot.
 * and actually, memory controller must be configured before U-Boot
 * is running in ram.
 */
ldr	r0, =0xff000fff
bic	r1, pc, r0		/* r0 <- current base addr of code */
ldr	r2, _TEXT_BASE		/* r1 <- original base addr in ram */
bic	r2, r2, r0		/* r0 <- current base addr of code */
cmp     r1, r2                  /* compare r0, r1     */
beq     1f			/* r0 == r1 then skip sdram init   */

/* init PMIC chip */

#ifdef CONFIG_ZSY210_IIC_PM_CHIP
bl PMIC_InitIp
#endif

/* init system clock */
bl system_clock_init
/* Memory initialize */
bl mem_ctrl_asm_init

1:
/* for UART */
bl uart_asm_init

/* for TZPC */
bl tzpc_asm_init

#if defined(CONFIG_NAND)
/* simple init for NAND /
bl nand_asm_init
#endif
/ check reset status */

ldr	r0, =(ELFIN_CLOCK_POWER_BASE+RST_STAT_OFFSET)
ldr	r1, [r0]
bic	r1, r1, #0xfffeffff
cmp	r1, #0x10000
beq	wakeup_reset_pre

/* ABB disable */
ldr	r0, =0xE010C300
orr	r1, r1, #(0x1<<23)
str	r1, [r0]

/* Print 'K' */
ldr	r0, =ELFIN_UART_CONSOLE_BASE
ldr	r1, =0x4b4b4b4b
str	r1, [r0, #UTXH_OFFSET]

mov	lr, r9
mov	pc, lr

uart_asm_init: Initialize UART’s pins
/
uart_asm_init:
/ set GPIO(GPA) to enable UART */
@ GPIO setting for UART
ldr r0, =ELFIN_GPIO_BASE
ldr r1, =0x22222222
str r1, [r0, #GPA0CON_OFFSET]

ldr r1, =0x2222
str r1, [r0, #GPA1CON_OFFSET]

ldr r0, =ELFIN_UART_CONSOLE_BASE @0xEC000000
mov r1, #0x0
str r1, [r0, #UFCON_OFFSET]
str r1, [r0, #UMCON_OFFSET]

mov r1, #0x3
str r1, [r0, #ULCON_OFFSET]

ldr r1, =0x3c5
str r1, [r0, #UCON_OFFSET]

ldr r1, =UART_UBRDIV_VAL
str r1, [r0, #UBRDIV_OFFSET]

ldr r1, =UART_UDIVSLOT_VAL
str r1, [r0, #UDIVSLOT_OFFSET]

ldr r1, =0x4f4f4f4f
str r1, [r0, #UTXH_OFFSET] @‘O’

mov pc, lr

tzpc_asm_init: Initialize TZPC
*/
tzpc_asm_init:

ldr r0, =ELFIN_TZPC0_BASE
mov r1, #0x0
str r1, [r0]
mov r1, #0xff
str r1, [r0, #TZPC_DECPROT0SET_OFFSET]
str r1, [r0, #TZPC_DECPROT1SET_OFFSET]
str r1, [r0, #TZPC_DECPROT2SET_OFFSET]

ldr r0, =ELFIN_TZPC1_BASE
str r1, [r0, #TZPC_DECPROT0SET_OFFSET]
str r1, [r0, #TZPC_DECPROT1SET_OFFSET]
str r1, [r0, #TZPC_DECPROT2SET_OFFSET]

ldr r0, =ELFIN_TZPC2_BASE
str r1, [r0, #TZPC_DECPROT0SET_OFFSET]
str r1, [r0, #TZPC_DECPROT1SET_OFFSET]
str r1, [r0, #TZPC_DECPROT2SET_OFFSET]
str r1, [r0, #TZPC_DECPROT3SET_OFFSET]

ldr r0, =ELFIN_TZPC3_BASE
str r1, [r0, #TZPC_DECPROT0SET_OFFSET]
str r1, [r0, #TZPC_DECPROT1SET_OFFSET]
str r1, [r0, #TZPC_DECPROT2SET_OFFSET]

mov pc, lr

/******************** zsy add 2013.3.14 ******************************/
/

Nand Interface Init for SMDKC110
*/
nand_asm_init:

/* Setting GPIO for NAND /
/ This setting is NAND initialze code at booting time in iROM. */

ldr r0, =ELFIN_GPIO_BASE

ldr r1, [r0, #MP01CON_OFFSET]
bic r1, r1, #(0xf<<8)
orr r1, r1, #(0x3<<8)
str r1, [r0, #MP01CON_OFFSET]

ldr r1, [r0, #MP01PUD_OFFSET]
bic r1, r1, #(0x3<<4)
str r1, [r0, #MP01PUD_OFFSET]

ldr r1, [r0, #MP03CON_OFFSET]
bic r1, r1, #0xFFFFFF
ldr r2, =0x22222222
orr r1, r1, r2
str r1, [r0, #MP03CON_OFFSET]

ldr r1, [r0, #MP03PUD_OFFSET]
ldr r2, =0x3fff
bic r1, r1, r2
str r1, [r0, #MP03PUD_OFFSET]

ldr r0, =ELFIN_NAND_BASE

ldr r1, [r0, #NFCONF_OFFSET]
ldr r2, =0x777F
bic r1, r1, r2
ldr r2, =NFCONF_VAL
orr r1, r1, r2
str r1, [r0, #NFCONF_OFFSET]

ldr r1, [r0, #NFCONT_OFFSET]
ldr r2, =0x707C7
bic r1, r1, r2
ldr r2, =NFCONT_VAL
orr r1, r1, r2
str r1, [r0, #NFCONT_OFFSET]

ldr r1, [r0, #NFCONF_OFFSET]
orr r1, r1, #0x70
orr r1, r1, #0x7700
str r1, [r0, #NFCONF_OFFSET]

ldr r1, [r0, #NFCONT_OFFSET]
orr r1, r1, #0x03
str r1, [r0, #NFCONT_OFFSET]

mov pc, lr

/******************** zsy add 2013.3.14 ******************************/
wakeup_reset_from_didle:
/ Wait when APLL is locked */
ldr r0, =ELFIN_CLOCK_POWER_BASE
lockloop:
ldr r1, [r0, #APLL_CON0_OFFSET]
and r1, r1, #(1<<29)
cmp r1, #(1<<29)
bne lockloop
beq exit_wakeup

wakeup_reset_pre:
mrc p15, 0, r1, c1, c0, 1 @Read CP15 Auxiliary control register
and r1, r1, #0x80000000 @Check L2RD is disable or not
cmp r1, #0x80000000
bne wakeup_reset @if L2RD is not disable jump to wakeup_reset

bl	disable_l2cache
bl	v7_flush_dcache_all
/* L2 cache enable at sleep.S of kernel
 * bl	enable_l2cache
 */

#ifdef CONFIG_ZSY210
bl enable_l2cache
#endif

wakeup_reset:
/* init system clock */
bl system_clock_init
bl mem_ctrl_asm_init
bl tzpc_asm_init
#if defined(CONFIG_NAND)
bl nand_asm_init
#endif

exit_wakeup:
/Load return address and jump to kernel/
ldr r0, =(INF_REG_BASE+INF_REG0_OFFSET)
ldr r1, [r0] /* r1 = physical address of s5pc110_cpu_resume function*/

mov	pc, r1		/*Jump to kernel */
nop
nop

system_clock_init: Initialize core clock and bus clock.
void system_clock_init(void)
*/
system_clock_init:

ldr r0, =ELFIN_CLOCK_POWER_BASE @0xe0100000

/* Set Mux to FIN */
ldr r1, =0x0
str r1, [r0, #CLK_SRC0_OFFSET]

ldr r1, =APLL_LOCKTIME_VAL
str r1, [r0, #APLL_LOCK_OFFSET]

/* Disable PLL */
#if defined(CONFIG_CHECK_MPLL_LOCK)
retryloop:
#endif
ldr r1, =0x0
str r1, [r0, #APLL_CON0_OFFSET]
ldr r1, =0x0
str r1, [r0, #MPLL_CON_OFFSET]

ldr r1, =0x0
str r1, [r0, #MPLL_CON_OFFSET]

ldr r1, [r0, #CLK_DIV0_OFFSET]
ldr r2, =CLK_DIV0_MASK
bic r1, r1, r2

ldr r2, =CLK_DIV0_VAL
orr r1, r1, r2
str r1, [r0, #CLK_DIV0_OFFSET]

ldr r1, =APLL_VAL
str r1, [r0, #APLL_CON0_OFFSET]

ldr r1, =MPLL_VAL
str r1, [r0, #MPLL_CON_OFFSET]

ldr r1, =VPLL_VAL
str r1, [r0, #VPLL_CON_OFFSET]
#if defined(CONFIG_EVT1)
ldr r1, =AFC_ON
str r1, [r0, #APLL_CON1_OFFSET]
#endif
mov r1, #0x10000
1: subs r1, r1, #1
bne 1b

#if defined(CONFIG_CHECK_MPLL_LOCK)
/* MPLL software workaround */
ldr r1, [r0, #MPLL_CON_OFFSET]
orr r1, r1, #(1<<28)
str r1, [r0, #MPLL_CON_OFFSET]

mov	r1, #0x100

1: subs r1, r1, #1
bne 1b

ldr	r1, [r0, #MPLL_CON_OFFSET]
and	r1, r1, #(1<<29)
cmp	r1, #(1<<29)
bne 	retryloop

/* H/W lock detect disable */
ldr	r1, [r0, #MPLL_CON_OFFSET]
bic     r1, r1, #(1<<28)
str	r1, [r0, #MPLL_CON_OFFSET]

#endif

ldr	r1, [r0, #CLK_SRC0_OFFSET]
ldr	r2, =0x10001111
orr	r1, r1, r2
str	r1, [r0, #CLK_SRC0_OFFSET]

#if defined(CONFIG_MCP_AC)

/* CLK_SRC6[25:24] -> OneDRAM clock sel = MPLL */
ldr	r1, [r0, #CLK_SRC6_OFFSET]
bic	r1, r1, #(0x3<<24)
orr	r1, r1, #0x01000000
str	r1, [r0, #CLK_SRC6_OFFSET]

/* CLK_DIV6[31:28] -> 4=1/5, 3=1/4(166MHZ@667MHz), 2=1/3 */
ldr	r1, [r0, #CLK_DIV6_OFFSET]
bic	r1, r1, #(0xF<<28)
bic	r1, r1, #(0x7<<12)	@; ONENAND_RATIO: 0
orr	r1, r1, #0x30000000
str	r1, [r0, #CLK_DIV6_OFFSET]

#elif defined (CONFIG_MCP_N)
/* CLK_SRC6[25:24] -> OneDRAM clock sel = 00:SCLKA2M, 01:SCLKMPLL */
ldr r1, [r0, #CLK_SRC6_OFFSET]
mov r1, #0x00000000
str r1, [r0, #CLK_SRC6_OFFSET]

/* CLK_DIV6[31:28] -> 0=1/1 */
ldr	r1, [r0, #CLK_DIV6_OFFSET]
mov	r1, #0x00000000
str	r1, [r0, #CLK_DIV6_OFFSET]

#elif defined (CONFIG_MCP_H)

/* CLK_SRC6[25:24] -> OneDRAM clock sel = 00:SCLKA2M, 01:SCLKMPLL */
ldr	r1, [r0, #CLK_SRC6_OFFSET]
bic	r1, r1, #(0x3<<24)
orr	r1, r1, #0x00000000
str	r1, [r0, #CLK_SRC6_OFFSET]

/* CLK_DIV6[31:28] -> 4=1/5, 3=1/4(166MHZ@667MHz), 2=1/3 */
ldr	r1, [r0, #CLK_DIV6_OFFSET]
bic	r1, r1, #(0xF<<28)
bic	r1, r1, #(0x7<<12)	@; ONENAND_RATIO: 0
orr	r1, r1, #0x00000000
str	r1, [r0, #CLK_DIV6_OFFSET]

#elif defined (CONFIG_MCP_B) || defined (CONFIG_MCP_D)

/* CLK_SRC6[25:24] -> OneDRAM clock sel = 00:SCLKA2M, 01:SCLKMPLL */
ldr	r1, [r0, #CLK_SRC6_OFFSET]
bic	r1, r1, #(0x3<<24)
orr	r1, r1, #0x01000000
str	r1, [r0, #CLK_SRC6_OFFSET]

/* CLK_DIV6[31:28] -> 4=1/5, 3=1/4(166MHZ@667MHz), 2=1/3 */
ldr	r1, [r0, #CLK_DIV6_OFFSET]
bic	r1, r1, #(0xF<<28)
bic	r1, r1, #(0x7<<12)	@; ONENAND_RATIO: 0
orr	r1, r1, #0x30000000
str	r1, [r0, #CLK_DIV6_OFFSET]

#elif defined (CONFIG_MCP_SINGLE)

/* CLK_DIV6 */
ldr	r1, [r0, #CLK_DIV6_OFFSET]
bic	r1, r1, #(0x7<<12)	@; ONENAND_RATIO: 0
str	r1, [r0, #CLK_DIV6_OFFSET]

#endif
mov pc, lr

#ifdef CONFIG_ENABLE_MMU

#ifdef CONFIG_MCP_SINGLE
/*

MMU Table for SMDKC110
0x0000_0000 – 0xBFFF_FFFF => Not Allowed
0xB000_0000 – 0xB7FF_FFFF => A:0xB000_0000 – 0xB7FF_FFFF
0xC000_0000 – 0xC7FF_FFFF => A:0x3000_0000 – 0x37FF_FFFF
0xC800_0000 – 0xDFFF_FFFF => Not Allowed
0xE000_0000 – 0xFFFF_FFFF => A:0xE000_0000 – 0XFFFF_FFFF
*/

/* form a first-level section entry */
.macro FL_SECTION_ENTRY base,ap,d,c,b
.word (\base << 20) | (\ap << 10) |
(\d << 5) | (1<<4) | (\c << 3) | (\b << 2) | (1<<1)
.endm
.section .mmudata, “a”
.align 14
// the following alignment creates the mmu table at address 0x4000.
.globl mmu_table
mmu_table:
.set __base,0
// Access for iRAM
.rept 0x100
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

// Not Allowed
.rept 0x200 - 0x100
.word 0x00000000
.endr
#ifdef CONFIG_ZSY10_1G
.set __base,0x200
// should be accessed
.rept 0x600 - 0x200
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr
#else
.set __base,0x200
// should be accessed
.rept 0x600 - 0x200
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr
/*
.set __base,0x400
// should be accessed
.rept 0x500 - 0x400
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr*/
#endif /* CONFIG_ZSY10_1G */
.rept 0x800 - 0x600
.word 0x00000000
.endr

.set __base,0x800
// should be accessed
.rept 0xb00 - 0x800
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

/* .rept 0xc00 - 0xb00
.word 0x00000000
.endr */

.set __base,0xB00
.rept 0xc00 - 0xb00
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

#ifdef CONFIG_ZSY10_1G
.set __base,0x200
// 256MB for SDRAM with cacheable
.rept 0xD00 - 0xC00
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr

// access is not allowed.
@.rept 0xD00 - 0xC80
@.word 0x00000000
@.endr

.set __base,0xD00
// 1:1 mapping for debugging with non-cacheable
.rept 0x1000 - 0xD00
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

#else
.set __base,0x200
// 256MB for SDRAM with cacheable
.rept 0xD00 - 0xC00
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr

// access is not allowed.
@.rept 0xD00 - 0xC80
@.word 0x00000000
@.endr

.set __base,0xD00
// 1:1 mapping for debugging with non-cacheable
.rept 0x1000 - 0xD00
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

#endif /* CONFIG_ZSY10_1G */
#else // CONFIG_MCP_AC, CONFIG_MCP_H, CONFIG_MCP_B

MMU Table for SMDKC110
0x0000_0000 – 0xBFFF_FFFF => Not Allowed
0xB000_0000 – 0xB7FF_FFFF => A:0xB000_0000 – 0xB7FF_FFFF
0xC000_0000 – 0xC7FF_FFFF => A:0x3000_0000 – 0x37FF_FFFF
0xC800_0000 – 0xDFFF_FFFF => Not Allowed
0xE000_0000 – 0xFFFF_FFFF => A:0xE000_0000 – 0XFFFF_FFFF
*/

/* form a first-level section entry */
.macro FL_SECTION_ENTRY base,ap,d,c,b
.word (\base << 20) | (\ap << 10) |
(\d << 5) | (1<<4) | (\c << 3) | (\b << 2) | (1<<1)
.endm
.section .mmudata, “a”
.align 14
// the following alignment creates the mmu table at address 0x4000.
.globl mmu_table
mmu_table:
.set __base,0
// Access for iRAM
.rept 0x100
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

// Not Allowed
.rept 0x300 - 0x100
.word 0x00000000
.endr

#if defined(CONFIG_MCP_N)
.set __base,0x300
// should be accessed
.rept 0x400 - 0x300
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr
#else
.set __base,0x300
// should be accessed
.rept 0x350 - 0x300
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr

// Not Allowed
.rept 0x400 - 0x350
.word 0x00000000
.endr

#endif

.set __base,0x400
// should be accessed
.rept 0x500 - 0x400
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr

.rept 0x800 - 0x500
.word 0x00000000
.endr

.set __base,0x800
// should be accessed
.rept 0xb00 - 0x800
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

.set __base,0xB00
.rept 0xc00 - 0xb00
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr

#if defined(CONFIG_MCP_N)
.set __base,0x300
// 256MB for SDRAM with cacheable
.rept 0xD00 - 0xC00
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr
#else
.set __base,0x300
// 80MB for SDRAM with cacheable
.rept 0xC50 - 0xC00
FL_SECTION_ENTRY __base,3,0,1,1
.set __base,__base+1
.endr

// Not Allowed
.rept 0xD00 - 0xC50
.word 0x00000000
.endr

#endif

.set __base,0xD00
// 1:1 mapping for debugging with non-cacheable
.rept 0x1000 - 0xD00
FL_SECTION_ENTRY __base,3,0,0,0
.set __base,__base+1
.endr
#endif

#endif























mem\_setup.S的完整代码:

#include <config.h>
#include <s5pv210.h>

.globl mem_ctrl_asm_init

mem_ctrl_asm_init:

#ifndef CONFIG_EVT1

ldr     r0, =ASYNC_MSYS_DMC0_BASE

ldr     r1, =0x0
str     r1, [r0, #0x0]

/* This register is removed at EVT1 of C110. */
ldr     r1, =0x0
str     r1, [r0, #0xC]

#endif

#ifdef CONFIG_MCP_SINGLE

/* DMC0 Drive Strength (Setting 2X) */

ldr	r0, =ELFIN_GPIO_BASE

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_0DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_1DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_2DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_3DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_4DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_5DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_6DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP1_7DRV_SR_OFFSET]

ldr	r1, =0x00002AAA
str	r1, [r0, #MP1_8DRV_SR_OFFSET]


/* DMC1 Drive Strength (Setting 2X) */

ldr	r0, =ELFIN_GPIO_BASE

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_0DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_1DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_2DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_3DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_4DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_5DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_6DRV_SR_OFFSET]

ldr	r1, =0x0000AAAA
str	r1, [r0, #MP2_7DRV_SR_OFFSET]

ldr	r1, =0x00002AAA
str	r1, [r0, #MP2_8DRV_SR_OFFSET]

/* DMC0 initialization at single Type*/
ldr	r0, =APB_DMC_0_BASE

ldr	r1, =0x00101000				@PhyControl0 DLL parameter setting, manual 0x00101000
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00000086				@PhyControl1 DLL parameter setting, LPDDR/LPDDR2 Case
str	r1, [r0, #DMC_PHYCONTROL1]

ldr	r1, =0x00101002				@PhyControl0 DLL on
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00101003				@PhyControl0 DLL start
str	r1, [r0, #DMC_PHYCONTROL0]

find_lock_val:
ldr r1, [r0, #DMC_PHYSTATUS] @Load Phystatus register value
and r2, r1, #0x7
cmp r2, #0x7 @Loop until DLL is locked
bne find_lock_val

and	r1, #0x3fc0
mov	r2, r1, LSL #18
orr	r2, r2, #0x100000
orr	r2 ,r2, #0x1000

orr	r1, r2, #0x3				@Force Value locking
str	r1, [r0, #DMC_PHYCONTROL0]

#if 0 /* Memory margin test 10.01.05 /
orr r1, r2, #0x1 @DLL off
str r1, [r0, #DMC_PHYCONTROL0]
#endif
/ setting DDR2 */
ldr r1, =0x0FFF2010 @ConControl auto refresh off
str r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0x00212400				@MemControl BL=4, 2 chip, DDR2 type, dynamic self refresh, force precharge, dynamic power down off
str	r1, [r0, #DMC_MEMCONTROL]

ldr	r1, =DMC0_MEMCONFIG_0			@MemConfig0 256MB config, 8 banks,Mapping Method[12:15]0:linear, 1:linterleaved, 2:Mixed
str	r1, [r0, #DMC_MEMCONFIG0]

ldr	r1, =DMC0_MEMCONFIG_1			@MemConfig1
str	r1, [r0, #DMC_MEMCONFIG1]

ldr	r1, =0xFF000000				@PrechConfig
str	r1, [r0, #DMC_PRECHCONFIG]

ldr	r1, =DMC0_TIMINGA_REF			@TimingAref	7.8us*133MHz=1038(0x40E), 100MHz=780(0x30C), 20MHz=156(0x9C), 10MHz=78(0x4E)
str	r1, [r0, #DMC_TIMINGAREF]

ldr	r1, =DMC0_TIMING_ROW			@TimingRow	for @200MHz
str	r1, [r0, #DMC_TIMINGROW]

ldr	r1, =DMC0_TIMING_DATA			@TimingData	CL=3
str	r1, [r0, #DMC_TIMINGDATA]

ldr	r1, =DMC0_TIMING_PWR			@TimingPower
str	r1, [r0, #DMC_TIMINGPOWER]

ldr	r1, =0x07000000				@DirectCmd	chip0 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@DirectCmd	chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00020000				@DirectCmd	chip0 EMRS2
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00030000				@DirectCmd	chip0 EMRS3
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010400				@DirectCmd	chip0 EMRS1 (MEM DLL on, DQS# disable)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000542				@DirectCmd	chip0 MRS (MEM DLL reset) CL=4, BL=4
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@DirectCmd	chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@DirectCmd	chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@DirectCmd	chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000442				@DirectCmd	chip0 MRS (MEM DLL unreset)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010780				@DirectCmd	chip0 EMRS1 (OCD default)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010400				@DirectCmd	chip0 EMRS1 (OCD exit)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x07100000				@DirectCmd	chip1 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@DirectCmd	chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00120000				@DirectCmd	chip1 EMRS2
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00130000				@DirectCmd	chip1 EMRS3
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110400				@DirectCmd	chip1 EMRS1 (MEM DLL on, DQS# disable)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100542				@DirectCmd	chip1 MRS (MEM DLL reset) CL=4, BL=4
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@DirectCmd	chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@DirectCmd	chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@DirectCmd	chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100442				@DirectCmd	chip1 MRS (MEM DLL unreset)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110780				@DirectCmd	chip1 EMRS1 (OCD default)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110400				@DirectCmd	chip1 EMRS1 (OCD exit)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x0FF02030				@ConControl	auto refresh on
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0xFFFF00FF				@PwrdnConfig
str	r1, [r0, #DMC_PWRDNCONFIG]

ldr	r1, =0x00202400				@MemControl	BL=4, 2 chip, DDR2 type, dynamic self refresh, force precharge, dynamic power down off
str	r1, [r0, #DMC_MEMCONTROL]

/* DMC1 initialization */
ldr	r0, =APB_DMC_1_BASE

ldr	r1, =0x00101000				@Phycontrol0 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00000086				@Phycontrol1 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL1]

ldr	r1, =0x00101002				@PhyControl0 DLL on
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00101003				@PhyControl0 DLL start
str	r1, [r0, #DMC_PHYCONTROL0]

find_lock_val1:
ldr r1, [r0, #DMC_PHYSTATUS] @Load Phystatus register value
and r2, r1, #0x7
cmp r2, #0x7 @Loop until DLL is locked
bne find_lock_val1

and	r1, #0x3fc0
mov	r2, r1, LSL #18
orr	r2, r2, #0x100000
orr	r2, r2, #0x1000

orr	r1, r2, #0x3				@Force Value locking
str	r1, [r0, #DMC_PHYCONTROL0]

#if 0 /* Memory margin test 10.01.05 */
orr r1, r2, #0x1 @DLL off
str r1, [r0, #DMC_PHYCONTROL0]
#endif

/* settinf fot DDR2 */
ldr	r0, =APB_DMC_1_BASE

ldr	r1, =0x0FFF2010				@auto refresh off
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =DMC1_MEMCONTROL			@MemControl	BL=4, 2 chip, DDR2 type, dynamic self refresh, force precharge, dynamic power down off
str	r1, [r0, #DMC_MEMCONTROL]

ldr	r1, =DMC1_MEMCONFIG_0			@MemConfig0	512MB config, 8 banks,Mapping Method[12:15]0:linear, 1:linterleaved, 2:Mixed
str	r1, [r0, #DMC_MEMCONFIG0]

ldr	r1, =DMC1_MEMCONFIG_1			@MemConfig1
str	r1, [r0, #DMC_MEMCONFIG1]

ldr	r1, =0xFF000000
str	r1, [r0, #DMC_PRECHCONFIG]

ldr	r1, =DMC1_TIMINGA_REF			@TimingAref	7.8us*133MHz=1038(0x40E), 100MHz=780(0x30C), 20MHz=156(0x9C), 10MHz=78(0x4
str	r1, [r0, #DMC_TIMINGAREF]

ldr	r1, =DMC1_TIMING_ROW			@TimingRow	for @200MHz
str	r1, [r0, #DMC_TIMINGROW]

ldr	r1, =DMC1_TIMING_DATA			@TimingData	CL=3
str	r1, [r0, #DMC_TIMINGDATA]

ldr	r1, =DMC1_TIMING_PWR			@TimingPower
str	r1, [r0, #DMC_TIMINGPOWER]


ldr	r1, =0x07000000				@DirectCmd	chip0 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@DirectCmd	chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00020000				@DirectCmd	chip0 EMRS2
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00030000				@DirectCmd	chip0 EMRS3
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010400				@DirectCmd	chip0 EMRS1 (MEM DLL on, DQS# disable)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000542				@DirectCmd	chip0 MRS (MEM DLL reset) CL=4, BL=4
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@DirectCmd	chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@DirectCmd	chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@DirectCmd	chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000442				@DirectCmd	chip0 MRS (MEM DLL unreset)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010780				@DirectCmd	chip0 EMRS1 (OCD default)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00010400				@DirectCmd	chip0 EMRS1 (OCD exit)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x07100000				@DirectCmd	chip1 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@DirectCmd	chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00120000				@DirectCmd	chip1 EMRS2
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00130000				@DirectCmd	chip1 EMRS3
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110440				@DirectCmd	chip1 EMRS1 (MEM DLL on, DQS# disable)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100542				@DirectCmd	chip1 MRS (MEM DLL reset) CL=4, BL=4
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@DirectCmd	chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@DirectCmd	chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@DirectCmd	chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100442				@DirectCmd	chip1 MRS (MEM DLL unreset)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110780				@DirectCmd	chip1 EMRS1 (OCD default)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00110400				@DirectCmd	chip1 EMRS1 (OCD exit)
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x0FF02030				@ConControl	auto refresh on
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0xFFFF00FF				@PwrdnConfig
str	r1, [r0, #DMC_PWRDNCONFIG]

ldr	r1, =DMC1_MEMCONTROL			@MemControl	BL=4, 2 chip, DDR2 type, dynamic self refresh, force precharge, dynamic power down off
str	r1, [r0, #DMC_MEMCONTROL]

#else /* CONFIG_MCP_SINGLE */

/* DMC0 initialization */
ldr	r0, =APB_DMC_0_BASE

ldr	r1, =0x00101000				@Phycontrol0 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00000084				@Phycontrol1 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL1]

ldr	r1, =0x00101002				@Phycontrol2 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00101003				@Dll on
str	r1, [r0, #DMC_PHYCONTROL0]

find_lock_val:
ldr r1, [r0, #DMC_PHYSTATUS] @Load Phystatus register value
and r2, r1, #0x7
cmp r2, #0x7 @Loop until DLL is locked
bne find_lock_val

and	r1, #0x3fc0
mov	r2, r1, LSL #18
orr	r2, r2, #0x100000
orr	r2, r2, #0x1000

orr	r1, r2, #0x3				@Force Value locking
str	r1, [r0, #DMC_PHYCONTROL0]

#if 1 /* DRAM margin test 10.01.06 */
orr r1, r2, #0x1 @DLL off
str r1, [r0, #DMC_PHYCONTROL0]
#endif
ldr r1, =0x0fff1010 @auto refresh off
str r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0x00212100
str	r1, [r0, #DMC_MEMCONTROL]

ldr	r1, =DMC0_MEMCONFIG_0
str	r1, [r0, #DMC_MEMCONFIG0]

ldr	r1, =DMC0_MEMCONFIG_1
str	r1, [r0, #DMC_MEMCONFIG1]

ldr	r1, =0xff000000
str	r1, [r0, #DMC_PRECHCONFIG]

ldr	r1, =DMC0_TIMINGA_REF
str	r1, [r0, #DMC_TIMINGAREF]

ldr	r1, =DMC0_TIMING_ROW			@TimingRow	@133MHz
str	r1, [r0, #DMC_TIMINGROW]

ldr	r1, =DMC0_TIMING_DATA
str	r1, [r0, #DMC_TIMINGDATA]

ldr	r1, =DMC0_TIMING_PWR			@Timing Power
str	r1, [r0, #DMC_TIMINGPOWER]

ldr	r1, =0x07000000				@chip0 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000032				@chip0 MRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x07100000				@chip1 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100032				@chip1 MRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x0FFF20B0			@ConControl auto refresh on
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0xFFFF00FF				@PwrdnConfig
str	r1, [r0, #DMC_PWRDNCONFIG]

ldr	r1, =0x00212113				@MemControl
str	r1, [r0, #DMC_MEMCONTROL]

/* DMC1 initialization */
ldr r0, =APB_DMC_1_BASE

ldr	r1, =0x00101000				@Phycontrol0 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00000084				@Phycontrol1 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL1]

ldr	r1, =0x00101002				@Phycontrol2 DLL parameter setting
str	r1, [r0, #DMC_PHYCONTROL0]

ldr	r1, =0x00101003				@Dll on
str	r1, [r0, #DMC_PHYCONTROL0]

find_lock_val1:
ldr r1, [r0, #DMC_PHYSTATUS] @Load Phystatus register value
and r2, r1, #0x7
cmp r2, #0x7 @Loop until DLL is locked
bne find_lock_val1

and	r1, #0x3fc0
mov	r2, r1, LSL #18
orr	r2, r2, #0x100000
orr	r2, r2, #0x1000

orr	r1, r2, #0x3				@Force Value locking
str	r1, [r0, #DMC_PHYCONTROL0]

#if 1 /* Memory margin test 10.01.05 */
orr r1, r2, #0x1 @DLL off
str r1, [r0, #DMC_PHYCONTROL0]
#endif
ldr r0, =APB_DMC_1_BASE

ldr	r1, =0x0FFF1010				@auto refresh off
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =DMC1_MEMCONTROL
str	r1, [r0, #DMC_MEMCONTROL]

ldr	r1, =DMC1_MEMCONFIG_0
str	r1, [r0, #DMC_MEMCONFIG0]

ldr	r1, =DMC1_MEMCONFIG_1
str	r1, [r0, #DMC_MEMCONFIG1]

ldr	r1, =0xff000000
str	r1, [r0, #DMC_PRECHCONFIG]

ldr	r1, =DMC1_TIMINGA_REF
str	r1, [r0, #DMC_TIMINGAREF]

ldr	r1, =DMC1_TIMING_ROW			@TimingRow	@133MHz
str	r1, [r0, #DMC_TIMINGROW]

ldr	r1, =DMC1_TIMING_DATA
str	r1, [r0, #DMC_TIMINGDATA]

ldr	r1, =DMC1_TIMING_PWR			@Timing Power
str	r1, [r0, #DMC_TIMINGPOWER]

ldr	r1, =0x07000000				@chip0 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01000000				@chip0 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05000000				@chip0 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00000032				@chip0 MRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00020020				@chip0 EMRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x07100000				@chip1 Deselect
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x01100000				@chip1 PALL
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x05100000				@chip1 REFA
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00100032				@chip1 MRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x00120020				@chip0 EMRS
str	r1, [r0, #DMC_DIRECTCMD]

ldr	r1, =0x0FFF10B0				@ConControl auto refresh on
str	r1, [r0, #DMC_CONCONTROL]

ldr	r1, =0xFFFF00FF				@PwrdnConfig
str	r1, [r0, #DMC_PWRDNCONFIG]

ldr	r1, =0x00212113				@MemControl
str	r1, [r0, #DMC_MEMCONTROL]

#endif /* CONFIG_MCP_AC / CONFIG_MCP_H / CONFIG_MCP_B / CONFIG_MCP_D / CONFIG_MCP_N */

mov	pc, lr

```
v7_flush_dcache_all()
```
```
Flush the whole D-cache.
```
```
Corrupted registers: r0-r5, r7, r9-r11
```

- mm    - mm_struct describing address space

*/
.align 5
.global v7_flush_dcache_all
v7_flush_dcache_all:

ldr	r0, =0xffffffff
mrc	p15, 1, r0, c0, c0, 1 		@ Read CLIDR
ands	r3, r0, #0x7000000
mov	r3, r3, LSR #23       		@ Cache level value (naturally aligned)
beq 	Finished
mov	r10, #0

Loop1:
add r2, r10, r10, LSR #1 @ Work out 3xcachelevel
mov r1, r0, LSR r2 @ bottom 3 bits are the Ctype for this level
and r1, r1, #7 @ get those 3 bits alone
cmp r1, #2
blt Skip @ no cache or only instruction cache at this level
mcr p15, 2, r10, c0, c0, 0 @ write the Cache Size selection register
mov r1, #0
mcr p15, 0, r1, c7, c5, 4 @ PrefetchFlush to sync the change to the CacheSizeID reg
mrc p15, 1, r1, c0, c0, 0 @ reads current Cache Size ID register
and r2, r1, #0x7 @ extract the line length field
add r2, r2, #4 @ add 4 for the line length offset (log2 16 bytes)
ldr r4, =0x3FF
ands r4, r4, r1, LSR #3 @ R4 is the max number on the way size (right aligned)
clz r5, r4 @ R5 is the bit position of the way size increment
ldr r7, =0x00007FFF
ands r7, r7, r1, LSR #13 @ R7 is the max number of the index size (right aligned)
Loop2:
mov r9, r4 @ R9 working copy of the max way size (right aligned)
Loop3:
orr r11, r10, r9, LSL r5 @ factor in the way number and cache number into R11
orr r11, r11, r7, LSL r2 @ factor in the index number
mcr p15, 0, r11, c7, c6, 2 @ invalidate by set/way
subs r9, r9, #1 @ decrement the way number
bge Loop3
subs r7, r7, #1 @ decrement the index
bge Loop2
Skip:
add r10, r10, #2 @ increment the cache number
cmp r3, r10
bgt Loop1
Finished:
mov pc, lr

   .align  5

.global disable_l2cache
disable_l2cache:
mrc p15, 0, r0, c1, c0, 1
bic r0, r0, #(1<<1)
mcr p15, 0, r0, c1, c0, 1
mov pc, lr

   .align  5

.global enable_l2cache
enable_l2cache:
mrc p15, 0, r0, c1, c0, 1
orr r0, r0, #(1<<1)
mcr p15, 0, r0, c1, c0, 1
mov pc, lr

   .align  5

.global set_l2cache_auxctrl
set_l2cache_auxctrl:
mov r0, #0x0
mcr p15, 1, r0, c9, c0, 2
mov pc, lr

   .align  5

.global set_l2cache_auxctrl_cycle
set_l2cache_auxctrl_cycle:
mrc p15, 1, r0, c9, c0, 2
bic r0, r0, #(0x1<<29)
bic r0, r0, #(0x1<<21)
bic r0, r0, #(0x7<<6)
bic r0, r0, #(0x7<<0)
mcr p15, 1, r0, c9, c0, 2
mov pc,lr

.align 5

CoInvalidateDCacheIndex:
;/* r0 = index */
mcr p15, 0, r0, c7, c6, 2
mov pc,lr

/* Below code is for ARM926EJS and ARM1026EJS /
.globl cleanDCache
cleanDCache:
mrc p15, 0, pc, c7, c10, 3 / test/clean D-Cache */
bne cleanDCache
mov pc, lr

.globl cleanFlushDCache

cleanFlushDCache:
mrc p15, 0, pc, c7, c14, 3 /* test/cleanflush D-Cache */
bne cleanFlushDCache
mov pc, lr

.globl cleanFlushCache

cleanFlushCache:
mrc p15, 0, pc, c7, c14, 3 /* test/cleanflush D-Cache /
bne cleanFlushCache
mcr p15, 0, r0, c7, c5, 0 / flush I-Cache */
mov pc, lr

.ltorg



.globl ledon_1

ledon_1:

既有适合小白学习的零基础资料，也有适合3年以上经验的小伙伴深入学习提升的进阶课程，涵盖了95%以上物联网嵌入式知识点，真正体系化！

需要这些体系化资料的朋友，可以加我V获取：vip1024c （备注嵌入式）

如果你需要这些资料，可以戳这里获取

0, #2 @ increment the cache number
cmp r3, r10
bgt Loop1
Finished:
mov pc, lr

   .align  5

.global disable_l2cache
disable_l2cache:
mrc p15, 0, r0, c1, c0, 1
bic r0, r0, #(1<<1)
mcr p15, 0, r0, c1, c0, 1
mov pc, lr

   .align  5

.global enable_l2cache
enable_l2cache:
mrc p15, 0, r0, c1, c0, 1
orr r0, r0, #(1<<1)
mcr p15, 0, r0, c1, c0, 1
mov pc, lr

   .align  5

.global set_l2cache_auxctrl
set_l2cache_auxctrl:
mov r0, #0x0
mcr p15, 1, r0, c9, c0, 2
mov pc, lr

   .align  5

.align 5

CoInvalidateDCacheIndex:
;/* r0 = index */
mcr p15, 0, r0, c7, c6, 2
mov pc,lr

/* Below code is for ARM926EJS and ARM1026EJS /
.globl cleanDCache
cleanDCache:
mrc p15, 0, pc, c7, c10, 3 / test/clean D-Cache */
bne cleanDCache
mov pc, lr
